US$ 12,800 - 13,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Type:
Other
Place of Origin:
Shanghai, China
Brand Name:
CHC
Contact Supplier Request Quote Chat Now
Shanghai Sursup Precision Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Other
Place of Origin Shanghai, China
Brand Name CHC
Model Number x91

Specifications

1.Dual-frequency RTK GNSS.
2.220-channel GPS+GLONASS+SBAS.
3.Integrated UHF+GSM/GPRS+Bluetooth.
4.Carlson SurvCE-software.

How could you provide the after-sale services for us?

For all instruments we are offing 1 year warranty. Our normal process for potential maintenance service is:
1. For small issues like missing or damaged part, key board, please send us the photos, we will send the required part and related instructions to you for free.
2. For big issues like EDX board, main board issue. We could only ask you to send the instrument back to us. Normally we will have it fixed in 10 working days and send back to you. You and we shall take care of the corresponding shipping cost on each side.

CHC X91 GNSS

KEY FEATURES :

1.FUTURE PROOF GNSS TECHNOLOGY

  Embedded leading GNSS core module GPS/GLONASS/GALILEO

2.CONNECTIVITY

 Built-in GPRS modem and UHF data link

3.COMPATIBILITY

 Seamless interoperability with major GPS/GNSS manufacturers

4.COMPACT & RUGGED

 Small, lightweight and rugged design for demanding





                                                Technical Specifications

 GNSS characteristic

 220 channels with simultaneously tracked satellite signals

− GPS: L1C/A,L2C, L2E, L5

− GLONASS: L1C/A, L1P, L2C/A, L2P

− SBAS: WAAS, EGNOS, MSAS

− Galileo: GIOVEA and GIOVEB

Advanced multipath mitigation

Low noise carrier phase measurement



Performance specifications

 Real Time Kinematics (RTK)

− Horizontal: 10mm+1ppm RMS

− Vertical: 20mm+1ppm RMS

− Initialization time: 10s

− Initialization reliability: typical >99.9%

Post Processing Static

− Horizontal: 2.5mm+1ppm RMS

− Vertical: 5mm+1ppm RMS

− Baseline Length: ≤300km



Communications

 *1x RS232 serial port and 1x high-speed USB

 *Integrated GSM/GPRS modem

 *Integrated Bluetooth ® communications port

 *Optional radio modem

    − CHC DL5: 1W-20W adjustable

    − Bandwidth: 410430 / 430450 / 450470 Mhz

 *Protocols

    − RTCM2.1, RTCM2.3, RTCM3.0, CMR, CMR+ input and output

    − NMEA0183 and GSOF outputs

    − RINEX and HCN outputs for GPS raw data



Physical

Size (H×D): 80mm×180mm

Weight: 1.25Kg with battery

Working Temperature: -30 °C to +65 °C

Storage Temperature: -40 °C to +75 °C

Humidity: 100% condensation

Dustproof: IP67

Waterproof : protected from temporary immersion to depth of 1 meter, floating.

Shock : survive a 2 meters drop onto concrete



Electrical

Typical power consumption: 2.6W

Battery capacity : 2200mAh

Operating times on internal battery : 9 hours (Static), 5 hours(RTK)

External power input : 9-18VDC



Data Controller

Operating System : Windows Mobile® 6.1 Professional

Processor : Marvell PXA310 806MHz

Display : 3.5" TFT LCD VGA (480 x 640)

Storage & Memory : 128MB MDDR, 256MB NAND flash and 4GB iNAND

Expansion Slots : SDIO / SDHC card slot (up to 16GB SDHC memory card)

IO Interface : Serial port (9-pin; D-sub), USB, Microphone, Speaker,

Communication Interface :

    − 3.5G WWAN (HSDPA / WCDMA / EDGE / GPRS / GSM)

    − 802.11 b/g

    − Bluetooth (v2.0 + EDR Class 2)

3M pixels auto focus camera with LED light

Power : Li-Ion smart battery (5600mAh)

Dimensions & Weight : 8.9 x 3 x 17.8 cm - 530 g

Rugged Features : MIL-STD-810G and IP67 certified

Operating temperature: -30°C to 60°C

Storage temperature: -40°C to 70°C

Humidity: 95% RH, non-condensing



Software

SurvCe ® field software

    − Complete data collection solution for RTK GPS and Total Stations (optional)

    − Combines advanced functionality and easeofuse.
