Specifications
1.Dual-frequency RTK GNSS.2.220-channel GPS+GLONASS+SBAS.
3.Integrated UHF+GSM/GPRS+Bluetooth.
4.Carlson SurvCE-software.
CHC X91 GNSS
KEY FEATURES :
1.FUTURE PROOF GNSS TECHNOLOGY
Embedded leading GNSS core module GPS/GLONASS/GALILEO
2.CONNECTIVITY
Built-in GPRS modem and UHF data link
3.COMPATIBILITY
Seamless interoperability with major GPS/GNSS manufacturers
4.COMPACT & RUGGED
Small, lightweight and rugged design for demanding
Technical Specifications
GNSS characteristic
220 channels with simultaneously tracked satellite signals
− GPS: L1C/A,L2C, L2E, L5
− GLONASS: L1C/A, L1P, L2C/A, L2P
− SBAS: WAAS, EGNOS, MSAS
− Galileo: GIOVEA and GIOVEB
Advanced multipath mitigation
Low noise carrier phase measurement
Performance specifications
Real Time Kinematics (RTK)
− Horizontal: 10mm+1ppm RMS
− Vertical: 20mm+1ppm RMS
− Initialization time: 10s
− Initialization reliability: typical >99.9%
Post Processing Static
− Horizontal: 2.5mm+1ppm RMS
− Vertical: 5mm+1ppm RMS
− Baseline Length: ≤300km
Communications
*1x RS232 serial port and 1x high-speed USB
*Integrated GSM/GPRS modem
*Integrated Bluetooth ® communications port
*Optional radio modem
− CHC DL5: 1W-20W adjustable
− Bandwidth: 410430 / 430450 / 450470 Mhz
*Protocols
− RTCM2.1, RTCM2.3, RTCM3.0, CMR, CMR+ input and output
− NMEA0183 and GSOF outputs
− RINEX and HCN outputs for GPS raw data
Physical
Size (H×D): 80mm×180mm
Weight: 1.25Kg with battery
Working Temperature: -30 °C to +65 °C
Storage Temperature: -40 °C to +75 °C
Humidity: 100% condensation
Dustproof: IP67
Waterproof : protected from temporary immersion to depth of 1 meter, floating.
Shock : survive a 2 meters drop onto concrete
Electrical
Typical power consumption: 2.6W
Battery capacity : 2200mAh
Operating times on internal battery : 9 hours (Static), 5 hours(RTK)
External power input : 9-18VDC
Data Controller
Operating System : Windows Mobile® 6.1 Professional
Processor : Marvell PXA310 806MHz
Display : 3.5" TFT LCD VGA (480 x 640)
Storage & Memory : 128MB MDDR, 256MB NAND flash and 4GB iNAND
Expansion Slots : SDIO / SDHC card slot (up to 16GB SDHC memory card)
IO Interface : Serial port (9-pin; D-sub), USB, Microphone, Speaker,
Communication Interface :
− 3.5G WWAN (HSDPA / WCDMA / EDGE / GPRS / GSM)
− 802.11 b/g
− Bluetooth (v2.0 + EDR Class 2)
3M pixels auto focus camera with LED light
Power : Li-Ion smart battery (5600mAh)
Dimensions & Weight : 8.9 x 3 x 17.8 cm - 530 g
Rugged Features : MIL-STD-810G and IP67 certified
Operating temperature: -30°C to 60°C
Storage temperature: -40°C to 70°C
Humidity: 95% RH, non-condensing
Software
SurvCe ® field software
− Complete data collection solution for RTK GPS and Total Stations (optional)
− Combines advanced functionality and easeofuse.
