Specifications
XH47S printing numbering offset presshigh quality and long use life
easy to operate
advanced technolog
XH-47S/56S/62S printing numbering offset press
Features:
Easy Operation by one hand lever to control dampening, inking and pressing.
Accurate Location by front stop and both side-pulled stop ensures perfect printing.
Dampening and Inking system is separate to adjust water and ink supplying easily.
PLC system is adopted to control the circuit.
Presetting Counter can make the machine stop automatically when finish preset quantity.
Double Sheets Detection can eliminate the troubles of multiple sheets automatically.
Powering Function can avoid paper dirty.
Centralized lubricating system is more convenient for maintenance
Numbering and perforating unit is optional.
Technical data of printing numbering offset press:
Model |
XH47S/XH47SNP |
XH-56S/XH56SNP |
XH62S/XH62SNP |
Max. paper width: |
470×365mm |
560x400mm |
620x440mm |
Max. printing area: |
454x345mm |
550x370mm |
605x440mm |
Min. paper size: |
210x297mm |
||
PS Plate size: |
470x395x0.15mm |
560x420x0.15mm |
620x485x0.15mm |
Rubber blanket size: |
466x415x1.95mm |
560x454x1.95mm |
620x510x1.95mm |
Paper weight: |
28~250gsm |
28~250gsm |
28~250gsm |
Register device: |
Wheel-type Side pull guide |
||
Feeding Mode: |
Suction, cross feed |
||
Dampening Mode: |
Molton Mode |
||
Ink Roller: |
10pcs(2 forme roller) 14pcs(3 forme roller) |
16pcs(3 forme roller) |
|
Dampening Roller: |
4pcs(1 forme roller)/5pcs(2 forme roller) |
5pcs(2 forme roller) |
|
Power: |
220V/50Hz(Single Phase) |
||
Power of Main Motor: |
1.1kw |
1.1kw |
1.65kw |
Power of Air-pump Motor: |
0.55kw |
0.55kw |
0.55kw |
Printing speed: |
2000~8000pcs/h |
2000~8000pcs/h |
2000~8000pcs/h |
Weight: |
600kg/800kg |
800kg/1000kg |
1000kg/1200kg |
Overall dimension: |
1.8x1.0x1.45m 2.1x1.0x1.45m(NP) |
1.8x1.1x1.45m 2.1x1.1x1.45m(NP) |
2.0x1.2x1.5m 2.3x1.2x1.5m(NP) |
Optional: | |||
Number capacity: |
Lateral: 7rowx7column=49/7rowx8column=56/7rowx9column=63 Vertical: 5rowx8column=40/5rowx10column=50/5rowx11column=55 |
||
