XH-47/56/62 D Double Color Offset Press double colors offset press machine
Features:
Easy Operation by one hand lever to control dampening, inking and pressing supply.
Accurate Location by front stop and both side-pulled stop ensures perfect printing.
Dampening and Inking system is separate to adjust water and ink supplying easily.
PLC system is adopted to control the circuit.
Presetting Counter can make the machine stop automatically when finish preset quantity.
Double Sheets Detection can eliminate the troubles of multiple sheets automatically.
Powdering Function can avoid paper dirty.
Centralized lubricating system is more convenient for maintenance
The numbering and perforating unit is optional. (Except the model XH62D)
Technical data:
Model |
XH47D/XH47DNP |
XH-56D/XH56DNP |
XH62D |
Max. paper width: |
470×365mm |
560x400mm |
620x440mm |
Max. printing area: |
454x345mm |
550x370mm |
605x440mm |
Min. paper size: |
210x297mm |
||
PS Plate size: |
470x395x0.15mm |
560x420x0.15mm |
620x485x0.15mm |
Rubber blanket size: |
466x415x1.95mm |
560x454x1.95mm |
620x510x1.95mm |
Paper weight: |
28~250gsm |
28~250gsm |
28~250gsm |
Printing speed: |
2000~8000pcs/h |
2000~8000pcs/h |
2000~8000pcs/h |
Register device: |
Wheel-type Side pull guide |
||
Feeding Mode: |
Suction, cross feed |
||
Dampening Mode: |
Molton Mode |
||
Ink Roller: |
10pcs(2 forme roller)/14pcs(3 forme roller) |
16pcs(3 forme roller) |
|
Dampening Roller: |
4pcs(1 forme roller)/5pcs(2 forme roller) |
5pcs(2 forme roller) |
|
Power: |
220V/50Hz(Single Phase) |
||
Main Motor Power: |
1.1kw |
1.1kw |
1.65kw |
Air-pump Motor Power: |
0.55kw |
0.55kw |
0.55kw |
Weight: |
650kg/850kg |
850kg/1050kg |
1050kg/1250kg |
Overall dimension: |
1.8x1.0x1.55m 2.1x1.0x1.55m(NP) |
1.8x1.1x1.55m 2.1x1.1x1.55m(NP) |
2.0x1.2x1.6m |
Optional: | |||
Number capacity: |
Lateral:7rowx7column=49/7rowx8column=56/ Vertical: 5rowx8column=40/5rowx10column=50 |
--- |
|
About XSHEEN Technology:
Any requirements can immediately contact me on or add Skype: xsheen2008
