100kg Cheap Used Hoist Lifting Price With Wire Rope
Description of 100kg Cheap Used Hoist Lifting Price With Wire Rope
1. Model CD1, MD1 wire rope electric hoist is small-sized lifting equipment.
2. With a compact, light weight, small size, parts versatility, easy operation.
3. Which can be mounted on single beam, overhead, gantry and jib cranes, with slight modification.
4. It can also be used as a winch.
5. It is widely used in factories, warehoused, cargo store areas and shops.
6. It is essential equipment in raising working efficiency and improving working conditions.
Characteristics of 100kg Cheap Used Hoist Lifting Price With Wire Rope
1. Compact electric hoist structure, the motor axis is perpendicular to the axis of the hoist drum using a worm gear.
2. Structure and characteristics:
The machine adopts mechatronics design, changing different molds; it can suppress the different specifications of the rope, the dominant simple, safe.
Application of 100kg Cheap Used Hoist Lifting Price With Wire Rope
Applications: lifting, pull shift, handling heavy loads, tanks flip chip bonding.such as:
installation and removal of various medium-sized concrete, steel, and machinery and equipment for construction and installation companies, civil construction and bridge construction factories, mines, electricity, shipbuilding, automobile manufacturing, construction, highways, bridges, metallurgical, mining, slope tunnels, wells and other infrastructure construction management protection of machinery and equipment.
Specifications of 100kg Cheap Used Hoist Lifting Price With Wire Rope
Type | Capacity (t) | Work Duty | Lift height (m) | Lift Speed (m/min) | Travel Speed (m/min) | Rope Diameter (mm) | Lifting Motor (kw) | Travelling Motor | Protection class | I-beam Track (mm) | N.W (kg) |
CD1/ MD1 | 0.5 | M3 | 6 | 8 8/0.8 | 20 20/6.7 30 30/10 | 4.8 | ZDY11-4(0.8) ZDS1-0.2/0.8 (0.2/0.8) | ZDY11-4 (0.2) | IP44 IP54 | 88-124 | 135 |
9 | 140 | ||||||||||
12 | 155 | ||||||||||
18 | 175 | ||||||||||
24 | 185 | ||||||||||
30 | 195 | ||||||||||
1 | M3 | 6 | 8 8/0.8 | 20 20/6.7 30 30/10 | 7.4 | ZD22-4(1.5) ZDS1-0.2/1.5 (0.2/1.5) | ZDY11-4 (0.2) | IP44 IP54 | 88-124 | 180 | |
9 | 190 | ||||||||||
12 | 205 | ||||||||||
18 | 220 | ||||||||||
24 | 235 | ||||||||||
30 | 255 | ||||||||||
2 | M3 | 6 | 8 8/0.8 | 20 20/6.7 30 30/10 | 11 | ZD31-4(3) (0.4/3) | ZDY12-4 | IP44 IP54 | 100-152 | 250 | |
9 | 265 | ||||||||||
12 | 300 | ||||||||||
18 | 320 | ||||||||||
24 | 340 | ||||||||||
30 | 360 | ||||||||||
3 | M3 | 6 | 8 8/0.8 | 20 20/6.7 30 30/10 | 13 | ZD32-4(4.5) ZDS1-0.4/4.5 (0.4/4.5) | ZDY12-4 (0.4) | IP44 IP54 | 100-152 | 320 | |
9 | 340 | ||||||||||
12 | 350 | ||||||||||
18 | 380 | ||||||||||
24 | 410 | ||||||||||
30 | 440 |
- Online Service: 24 hours online service
- Quickly Response: response within at most 8 hours
- Quality Guarantee Terms: Quality guarantee term is for one year. Malfunctions which are caused by machine-self and quality will be responsible for our manufacturer. Other malfunctions which are caused by operation mistakes, man-made problems, etc will be responsible for clients-self.
- Spare parts: cheapest spare parts
- Delivery: Fast delivey with safety
- CEO will refund on reasonable and complain
- What are the raw material?
- What capacity machine would you like?
- Which power do you perfer? Electric. diseal and gasoline?
- What you closest sea port?
- What is the instustrial voltage in your country?
Contacts
Looking forward to your inqury on our 100kg Cheap Used Hoist Lifting Price With Wire Rope.
