Sliding Window Profiles 80 Series

Sliding Window Profiles 80 Series thumbnail-1
Sliding Window Profiles 80 Series photo-1
US$ 1,300 - 1,800 MOQ: 10 Tons
Key Specifications
Get Latest Price
Place of Origin:
Anhui, China
Brand Name:
CONCH
Model Number:
80
Contact Supplier Request Quote Chat Now
Shanghai Conch Profiles Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
wuhu shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Anhui, China
Brand Name CONCH
Model Number 80
Frame Material Plastic

Specifications

Conch 80 sliding window profiles
1Energy saving
2Guard against theft
3Good sound insulation
4Sunshade and protect privacy

The features of Conch 80 sliding window profile:

1. Excellent heat preservation performance

Plastic has heat conductivity factor, and has a heat insulation effect 1250 times better than aluminum material.

2. Good sound insulation performance

Its structure is designed very well, with tight joints. The test result indicates that its sound insulation is <20db and complies with DIDN4109.

3. Anti-aging

Imported denaturalizing agent is applied, and the agent for preventing UV rays absorption is added in the raw materials. The product does not discolor, and become aging or brittle even when it is exposed to direct sunlight, rainstorm, drying or humidity between -30°C and 70°C.

4. Good combustion-retarding performance

Plastic window is made of quality combustion-retarding material, and does not ignite itself or support combustion and can extinguish the fire by itself. So it is your ideal choice.

5. Resist impacts

Special impact-resisting design is applied, and the section material can bear cold impact test of 1kg hammer dropping freely from one meter height at-10°C.

6. Good waterproof performance

Its water absorption is <0.1%. The doors and windows are designed to have rainproof plates and water drain slots, and can completely isolate the rainwater outside of your room. Its waterproof performance complies with DIDN18055.

7. Good anti-theft

Plastic door and windows are provided with high-quality metal articles. Inside of windows will be fitted with glass strips according to the design so that thieves have no solutions.

8. Easy maintenance

Plastic sections are not corroded and do not discolor or get yellow. They are not affected by ash, cement or binding agents, so they almost need no maintenance.

9. Good air tightness

All the joints and gaps of the plastic windows are fitted with ternary sealing strips, and unit length of gaps can vent below 4m³mmhm. In the house equipped with cold and heating facilities, the plastic window can be fully jtilized as air-conditioners, and can save energy.



Window Model:



sliding window profiles 80 series



80 sliding window

Name

Code

Baiting size

(mm)

Piece

Length(m)

Kg/m

Total Weight(Kg)

Frame

HF80NC

1476

2

5.904

1.198

7.0730

1476

2

Mullion

SE70NC

1512

1

1.512

1.528

2.3103

Sash

SF55NC

724.5

4

6.518

0.736

4.7972

905

4

Double glass bead

GB8NC

640.5

4

5.846

0.126

0.7366

821

4

Fixed window frame

FB80-1NC

1366

2

3.558

0.66

2.3483

413

2

Double glass bead (Fixed window)

GB8NC

1342

2

3.462

0.126

0.4362

389

2

Inner lock

IL31NC

899

2

1.798

0.201

0.3614

Screen sash

MF52NC

721.5

2

3.253

0.492

1.6005

905

2

KG/pc window

19.6635

Percentage of outturn

114.42m2/T





80 sliding window (transmission)

Name

Code

Baiting size

(mm)

Piece

Length(m)

Kg/m

Total Weight(Kg)

Frame

HF80NC

1476

2

5.904

1.198

7.0730

1476

2

Mullion

SE70NC

1512

1

1.512

1.528

2.3103

Sash

SF66-37NC

730

4

6.54

0.876

5.7290

905

4

Double glass bead

GB8NC

624

4

5.692

0.126

0.7172

799

4

Fixed window frame

FB80-1NC

1366

2

3.558

0.66

2.3483

413

2

Double glass bead (Fixed window)

GB8NC

1342

2

3.462

0.126

0.4362

389

2

Inner lock

IL36-37NC

899

2

1.798

0.219

0.3938

Screen sash

MF52NC

716

2

3.242

0.492

1.5951

905

2

KG/pc window

20.6029

Percentage of outturn

109.21m2/T



Profiles Section Drawings:

 sliding window profiles 80 series





Real product photo show :



 sliding window profiles 80 series



 sliding window profiles 80 series
