1 Minute Installation Original Mazda Car Window Closer

1 Minute Installation Original Mazda Car Window Closer thumbnail-1
1 Minute Installation Original Mazda Car Window Closer photo-1
Negotiable MOQ: 300 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Battlesnake
Model Number:
For Mazda
Contact Supplier Request Quote Chat Now
Guangzhou Carform Electronics Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Battlesnake
Model Number For Mazda

Original Subaru car window closer



Advantages:



Original Car Window Closer
Compatible with the original car remotes,press original car remote, four windows can be closed
With the original car's CAN data, can be controlled by the original car's CANBUS network, working reliably
OBD socket plug and play to the original car, or use some clip to connect the original car cable. No need to cut!
Easy for installation, can save 90% time.
Jpanese standard cables specialized for the original car manufacture required, High Quality



VS
Universal Car Window Closer
Use the aftermarket car alarm remote controller
Controlled by the relays electric output, short working life, easier destroy the car's circuit.
Need to cut the orginal cars cable and connect them one by one
Take time to install it
Chinese Standard cables. Not suit for original car maufacture required.





1-No need to cut any wire, just plug the above sockets are ok!



2-Need to connect the power cable by Clips.



Photoes:



1 minute installation Original Mazda car window closer1 minute installation Original Mazda car window closer1 minute installation Original Mazda car window closer

MAZDA original window closer system with the following items(As per the car type):

Item No. Car type Basic Model Deluxe Mode Need to connect the wire (for basic model) Need to connect the wire (for Deluxe model)
CF-WM58 MAZDA Qiubite,HAIMA1,HAIMA3 HB,FAMIY,FAMIY 2,FAMIY 3,FAMIY 323,Pulima,haifuxing,qishi suv made in China Hainan province Yes Yes Need to connect with 1 wire Need to connect with 2 wire
CF-WM59 MAZDA 2 Yes Yes Need to connect with 1 wire Need to connect with 2 wire
CF-WM60 MAZDA 3 Yes Yes Need to connect with 2 wire Need to connect with 3wire
CF-WM61 MAZDA 3 imported cars Yes Yes Need to connect with 1 wire Need to connect with 2 wire
CF-WM62 MAZDA 5 Yes Yes Need to connect with 2 wire Need to connect with 3 wire
CF-WM63 MAZDA 6 old Yes Yes Need to connect with 1 wire Need to connect with 2 wire
CF-WM64 MAZDA 6 New Yes No Need to connect with 1 wire -







Specifications:



Technology Parameters of Original Car Window Closer



1 Operating Voltage 13V-11V 3 Operating Current 6A
2 Static Current 8mA 4 Protecting Current 9.5mA
6 Acc lowest voltage 9V 5 Protecting time 6secs



Technology Parameters of Power Windows



1 Operating Voltage 15V-11V 3 Operating Current 12A
2 Static Current 3mA 4 Application temperature +80 to -20





Functions:



This is a new upgrade car window closerwith the original fittings, compatible with the original car's CANBUS data, can be finished the installation in 20 mins. because it get the original car's socket, keep all function as original car's alarm features, can be used the remote controller of the original car.



1 Compatible with the original car's CANBUS communication data, control the car window close.
2 Use Original Car Remote Control to close the windows.





Packing details:



  size quantity Weight
color box 17*12*6.5cm 1pcs 0.5kgs
carton 35.5*25.5*34cm 20pcs 11kgs
20GP container 28CBM(909cartons) 18180pcs 9999kgs





Payment term:



1-T/T

2-L/C

3-WESTER UNION

4-PAYPAL

5 Ali-express: /store/212031







About us:



1 minute installation Original Mazda car window closer1 minute installation Original Mazda car window closer
