Specifications
fixed RFID reader with built in wifi and gprs, RFID reader with built in wifi and gprs-Double Core,>500tag identify
-4 antenn
fixed RFID reader with built in wifi and gprs, RFID reader with built in wifi and gprs
Introduction & feature:
Double industrial CPU design, Keep high performance and 24hrs X 365days no crash
ISO18000-6C/6B protocols compatible
Special dynamic Q anti-collision algorithm brings out excellent multi tag function
9dBi specialized antenna, up to stable 12m-15m reading distance.
Split Type and standard installing design, Very convenient In Site Operation
IP65, Sturdy and durable because of high strength integrative cast aluminum body
-85dBm high sensitivity
Chinese No.1 UHF RFID long Range RFID manufacturer!!!
Application:
- Traffic (Express Way, Parking Lot): ETC (Electronic Toll Collection) , Vehicle Checking, Management
- Retail (Sales Floor; POS; backroom): Inventory/cycle counting, Automatic replenishment, Receiving/shrink control, Item finding
- Enterprise (Business offices/carpeted spaces), Asset/IT management, File and document tracking, Item finding
- Healthcare(Hospitals; clinics), Asset management (for high value critical assets), Patient tracking,, Item finding
- Manufacturing / Warehousing(Animal Mangagement system;Production line; Warehouse aisles and loading docks)
- Logistic / Supply Chain Express; Container tracking Inventory/cycle counting Receiving/shrink control Item finding
The Best RFID high-tech production equipments in China!!!
We have very strict inspection process!!!!
Specification:
CPU: | Double CPU design | |
Chip: | Special High performance Impinj UHF RIFD chip | |
Working Voltage: | 3.7V – 5 V | |
| Standby Current: | <50mA (EN Feet high level)) |
| Sleep Current: | <100uA (EN feet low level) |
| Working Current: | 1.2A +/-10% |
| Working Temperature: | - 20 °C - + 55 °C |
| Storage Temperature: | - 20 °C - + 85 °C |
| Relative Humidity: | < 95% ( + 25 °C) |
| Interface Protocol: | EPC global UHF Class 1 Gen 2 / ISO 18000-6C ISO 18000-6B |
| Frequency Range: | 860Mhz – 960Mhz |
| Working Area supported: | US, Canada and other regions following U.S. FCC Europe and other regions following ETSI EN 302 208 with & without LBT regulations Mainland China Japan, Korea, Malaysia, Taiwan |
| Output Power: | 20 – 33dBm |
| Power Precision: | +/- 1dB |
| Power Flatness: | +/- 0.2dB |
| Receiving Sensitivity: | < -85 dBm |
| Inventory Peak Speed: | > 500pcs |
| Tags Buffer Cache: | 800pcs @ 96 bit EPC |
| Tag RSSI | Supported |
| Antenna Connection Protection: | Supported |
| Temperature Monitoring: | Supported |
| Working Mode: | Single/Intensive Mode |
| Communication Interface: | TTL UART(RS232) Interface |
| GPIO | 2 input, 2 output (3.3V level) |
| Baud Rate | 115200 bps |
| Heat-dissipating Method: | External cooling fin |
Most Professional Technology Support Team 20persons X 8hrs each working day for you!!!
Our Chief engineer often serve you directly for development.
If you still have any RFID application questions, email or call Liz now. I will give you best answer.
