Specifications
industrial aluminum cleaning machinesmore secure
Shock proof
easy for operation
Ultrasonic Generator
industrial aluminum cleaning machines on sale
Process Of Cavitations
The frequency beyond audible limit is called Ultrasonic Frequency. A normal frequency of 28kHz is converted to very high ultrasonic frequency. Transducers, bonded to the bottom or side of the tank convert this frequency into mechanical energy. High intensity Ultrasound in liquid creates high & low pressure zones. Under the influence of low pressure period, microscopic bubbles get formed in vacuum form. These bubbles get compressed & eventually collapse & burst. This process is called "Cavitation."
Cleaning Action
Collapse or implode of the cavities releases tremendous energy and produces an intense scrubbing action on immersing the aluminum cleaning machinesin the liquid, for cleaning. The scrubbing action created by cavitation dislodges particulates matter from the object surface. It is literally like having millions of microscopic bombs going off. The concussion of these bombs, blasts flux particles loose from the object , but without harming its surface. Cavitations is not a localized event. It permeates the entire tank of liquid. This is why ultrasonic pcb cleaners works so well with complex part geometry and small work pieces features. The scrubbing action is able to access even small recesses. The classic example of application is cleaning of SMT/Densely populated PC Boards.
Advantage
- Long working life
- High conversion efficiency and energy-saving.
- Manufactured with advanced technology with germany`s Siemens.
- Top qualitystainlesssteel made for body, cover and base,professional testing, quality assurance
- Novel structure, high reliability, high efficiency, and low noise
- Multi ultrasonic directions ensure completely and thoroughly cleaning for the parts
- Unique design of saw-teeth water overflowing to ensure proper level and that the dirt can timely be escaped
- Drain Faucet for spill-proof draining.
- Time setting:1-99 hours adjustable
- Powerful transducer and clear circuit
Model | Tank size(mm) | Ultrasonic power | Heating power | Ultrasonic direction | Voltage |
BK-1800 | 600x480x450 | 1.8KW | 4KW | 3 sides | 380V |
BKU-1800 | 700X400X350 | 1.8KW | 4KW | 3 sides | 380V |
BK-2400 | 750X550X480 | 2.8KW | 6KW | 3 sides | 380V |
BK-3600 | 1000X550X560 | 3.6KW | 9KW | 3 sides | 380V |
BK-4800 | 1200X650X650 | 5.2KW | 12KW | 3 sides | 380V |
BK-6000 | 1450X720X730 | 7.2KW | 15KW | 3 sides | 380V |
BK-7200 | 1500X800X800 | 8.0KW | 18KW | 3 sides | 380V |
BK-10000 | 1700X900X800 | 10.8KW
| 20KW or steam | 3 sides | 380V |
BK-12000 | 2200X1200X1000 | 21.6KW | 32KW or steam | 3 sides | 380V |
NOTE: | If the requested size is not appeared in the above table, we company will glad to manufacture according to your request. | ||||
Cleaning effect:
Company info:
Established in 2004, Jinan Bakr Ultrasonic Technology Co., Ltd. is a CE and ISO certified company, engaged in manufacturing and supplying a quality range of cleaning machine, especially ultrasonic cleaner ,for over 10 years. We are located in Jinan city, which has convenient transportation condition. All of our products comply with international quality standards and are greatly appreciated in a variety of markets around the world.
Covering an area of 400,000 square meters, we now have over 200 employees and an annual sales figure that exceeds USD8,000,000. We are currently exporting 60% of our products worldwide. Our well-equipped facilities and excellent quality control throughout all stages of production enable us to guarantee total customer satisfaction. Besides, we have received ISO9001 & CE certifications.
