Specifications
professionl ultrasound cleaner,resist high temperature80,highpressure,overheating.Adjustable power,imported partsIndustrial Cleaning Cleaner for engine part
Jinan Bakr professionally produce ultrasonic cleaning machine,our products have lots of advantages:
Ultrasonic cleaner series are mainly used in laboratory ,medical and dental clinics,electronic workshops,also can be applied to semi-conductor silica chip,optical glass,Jewelry,Watches straps and bands,glasses,dentures,toothbrushes,tableware,hardware,plastic ceramic parts.
· Bakr is the first one to use full-bridge IGBT high-power integration modules-Germany Siemens to control power source,good protection against high temperature,high pressure and overheating,makes the cleaner perfect.
· Withstand high temperature.it can reach up to 80°C, Siemens modules is of high pressure resistance,as transistor and filed effect tube can be easily be broken down by current under high voltage,not only affecting the normal function but also disturbing the transducer's frequency,Siemens can avoid this.
· Siemens module control power is higher than other components; Bakr`s control circuit adopts the most advanced power adjustment according to different components.
Adopting original Germany CeramTec piezoelectric ceramic chip,high-precision CNC machine equipment and accurate test methods ensure Bakr high quality.And tank adopts expoted 2mmSUS304 stainless steel.
·Good outlook, low defective rate, easy operation and professional style.
Model Specification | BKU900 | BKU-1800 | BK-1800 | BK-2400 | BK3600 | BK-4800 | BK-6000 | BK-7200 |
BK-10000
| BK-12000 |
Ultrasonic Power | 900W | 1.8KW | 1.8KW | 2.8KW | 3.6KW | 5.2KW | 7.2KW | 8.0KW | 14.4KW | 21.6KW |
Heating Power | 1KW | 4KW | 4KW | 6KW | 8KW | 9KW | 12KW | 16KW | 20KW or steam | 32KW or steam |
Voltage | 380V | 380V | 380V | 380V | 380V | 380V | 380V | 380V | 380V | 380V |
Tank Size(mm) | 400*300*300 | 700*400*350 | 600*480*450 | 750*550*480 | 1000*550*560 | 1200*650*650 | 1450*720*730 | 1500*800*800 | 1700*900*800 | 2200*1200*1000 |
Product Size(mm) | 560*460*600 | 1000*750*700 | 760*770*680 | 910*850*770 | 1160*850*870 | 1400*1030*980 | 1650*1190*1100 | 1700*1280*1150 | 1960*1450*1150 | 2500*1800*1350 |
Ultrasonic direction | Down side | Down side | Three sides | Three sides | Three sices | Three sides | Three sides | Three sides | Three sides | Three sides |
Have dregs tank or not | have | have | have | have | have | have | have | have | have | have |
Have overflow device or not | without | without | have | have | have | have | have | have | have | have |
