4QZ-1800 Self-propelled Corn silage machinery for sale

4QZ-1800 Self-propelled  Corn silage machinery for sale

1. The design of double discs header feeds all the crops uniformly into drum, which can cut all the stalks within the working width(not row by row), to improve the yield rate.

2. Adopted upright feeding roller, upright chaff cutter, which is simple structure and stable performance, not only cutting off the straw cuticle, but also retaining the nutrients,

3. They are equipped with YTO inline 4-cylinder with 140 hp engine, efficient and high-powered.

4. The new cab with 270 degree wide field of vision and simple operating system makes it easy to drive.

5. Equipment with storage containers of forage makes forages recycle and harvest more convenient.

6. Big track and short wheelbase make it convenient and flexible to bend and turn

7. High efficiency, low price, and low fuel consumption, make this machine become more and more small and middle size pasture’s first choice.

Specifications:

Item	Unit	Specification
Model		4QZ-1800
Overall dimension (length, width, height)	mm	5000*1800*2900
Net weight	kg	4000
Engine power	hp	140
Mainshaft speed of cutting device	r/min	1300
Header width	mm	1800
Header up-down scope	mm	0-400
Cutting device Structure		upright
Throwing drum turning angle	°	360
Rotor diameter of cutting device	mm	800
Fragment length	mm	Adjust the quantity of the saws
Throwing height	mm	4300
Throwing distance	mm	≥3000
Walking velocity	km/h	1-10



Machine photos













More details

Customer visit factory

Storage



Company Information

About Dingguagua

Hebei Dingguagua Machinery Manufacturing Co.,Ltd. is a high-tech modern agricultural machinery manufacturing company, professionally engaged in R&D design, manufacturing, sales and promotion of agricultural machinery with abundant R&D and production capability. Its products have become synonymous with quality and reliability. The company has an occupation area of 54,000 square meters and a building area of 38000 square meters; we now totally have 260 employees; 40 of them are R&D personnel with high education level; at present, the company has an annual production capacity of various agricultural machines of 150,000 sets, including 12 major series and 50 varieties of products. In addition, we own six China national practical new-type patents.

Major products include:

1) cultivator with fertilizer

2) self-propelled forage harvester

3) mini-tiller

4) seeders(for different crops)





Participating in professional exhibitions



If you are interested in our products,plz feel free to contact me for more information and working video.
