250W 300w Mono 12v Solar Panel

US$ 0.6 - 0.87 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

CAP

Model Number:

HL-seris

Guangzhou CAP Solar New Energy Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port of china

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name CAP

Model Number HL-seris

Specification Normal

Application Industrial

Output Voltage (V) 36/18 v

Solar Power (W) 300w

Work Time (h) 8

Specifications

12v solar panel
1) high efficency
2) easy to install
3) stand heavy rain and snow
4) lower price

1) high efficency

2) easy to install

3) stand heavy rain and snow

4) lower price


Model Number		HL-275	HL-280	HL-285	HL-290	HL-295	HL-300
Maximum Power as per STC	Pmax(W)	275	280	285	290	295	300
Power Tolerance	%	± 3%
Maximum Power Voltage	Vm(V)	36.43	36.56	36.72	36.79	36.93	37.15
Maximum Power Current	Im(A)	7.55	7.66	7.77	7.89	7.99	8.08
Open Circuit Voltage	Voc(V)	43.7	42.92	44.06	44.21	44.35	44.5
Short Circuit Current	Isc(A)	8.1	8.17	8.23	8.33	8.41	8.72
Maximum System Voltage	VDC	1000
Cell Efficiency	%	15.8	16.1	16.4	16.7	17.0	17.3
Module Efficiency	%	14.2	14.5	14.7	15.0	15.2	15.5
Cells per Module	Pcs	72
Cell Type		Monocrystalline silicon
Cell Size	mm	156 x 156
Bypass Diodes	Pcs	12Amp, 6 pcs
Max. Series Fuse Rating	A	15A
Temperature coefficient of Isc	%	0.05
Temperature coefficient of Voc	%	-0.35
Temperature coefficient of power	%	-0.47
NOCT- Nominal operating cell temperature		47 ± 2 degree
Operating Temperature		from -40 to +85 degree
MECHANICAL CHARACTERISTICS
Dimensions	mm	1950x 990 x 50
Weight	Kg	23.5
Type of Junction Box		TUV certified, IP65
Cable Type, Diameter		TUV certified, 4mm 2, 90 cm in length
Connector		compatible to Type 4 (MC4)
Tempered Glass		3.2 mm, high transmission, low iron
