Help Center1000w 2000w Portable Solar Generator
Related Products
-
1000w 2000w 3000w Solar Box,protable Solar System,mini Solar Power SystemUS$ 220 - 1,500MOQ: 1 Set -
1000w 2000w 3000w Portable Home Inverter for Protable Solar SystemUS$ 220 - 1,500MOQ: 1 Set
-
600w 1000w 2000w Solar Home KitsUS$ 220 - 1,500MOQ: 1 Set
-
1000w 2000w Portable Outdoor Solar Power SystemsUS$ 220 - 1,500MOQ: 1 Set
-
Home Use 1000w 2000w 3000w Protable Solar BoxUS$ 220 - 1,500MOQ: 1 Set
Specifications
portable solar generator1.LED display
2,inverter,controller,battery three in one
3,minio size protable solar syste
portable solar generator
Characteristics:
1. Modified sine wave output
2. Different choice of input voltage range
3. High-frequency digital technology, MCU control, more stable capablity
4. High efficiency rate of DC - AC conversion, minimize energy loss
5.Tower design, can both stand up and lay down, can be placed flexibly
6. Equiped with super-charger, the maximum electricity can reach 8 A, and can charge for batteries with electricity over 100 AH
7.Intelligent charge control, can ensure the effective charging,but can not avoid excessive charging
8. Restoration of electricity, automatically activated
9. Offline-charging functions (when the utility comes to normal, even if it is not turned on, the machine can still charge the battery)
10. Multi-functional LED indicator light and alarm device
2.Specification
MODEL |
115V Models |
230V Models |
OUTPUT | ||
Power Levels crated at nominal inputs |
500VA/300W;1000VA/600W;2000VA/1200W |
500VA/300W;1000VA/600W;2000VA/1200W |
Output Voltage |
120V |
230V |
Phase |
Singthree phase |
|
Voltage Waveform |
Pure Sine Wave |
|
Power Factor |
0.6 |
|
Output Frequency(Synchronized to Mains) |
Auto Select for 50/60Hz |
|
Regulation (Nominal) |
10%-18% |
|
Regulation(Battery mode) |
±0.1HZ |
|
Transfer time |
8ms Typical |
|
INPUT | ||
Nominal Voltage |
110V/120V Selectable |
220V/230V/240V Selectable |
Phase |
Single |
|
Voltage range |
90 - 145VAC or 170-280VAC ( Narrow Range ) |
|
50-145VAC / 90-280VAC (Wide Range) | ||
BATTERY | ||
Charger Current |
500VA/300W/12VDC:10 Amp + / -
1Amp;1000VA/600W/12VDC/:10Amp + / -
1Amp; 2000VA/1200W/24VDC:10 Amp + / - 1Amp |
|
Overcharge Protection |
500VA/300W: 15V +/- 0.3V charger stops and fault |
|
1000VA/600W:15V +/- 0.6V charger stops and fault | ||
2000VA/1200W: 30V +/- 0.6V charger stops and fault | ||
EFFICIENCY | ||
AC to AC |
>95% |
|
DC to AC |
>80% |
|
INDICATOR | ||
AC Mode |
Green LED lighting |
|
Battery Mode |
Yellow LED lighting |
|
Battery Charging Mode |
Green LED flashing every 2 seconds |
|
Overload |
Red LED flashing every 0.5 second |
|
Fault |
Red LED lighting |
|
AUDIBLE ALARM | ||
Low Battery at Battery Mode |
Sounding every 2 seconds |
|
Overload |
Sounding every 0.5 second |
|
Fault |
Continously sounding |
|
Protection | ||
Full Rrotection |
Deep Discharge, Overcharge, and Overload protection |
|
ENVIRONMENTAL AND SAFETY | ||
Operating Temperature |
Up to 1500 meters:0 °C to 40°C (32°F to 104°F) |
|
Transit/storage Temp. |
15°C below zero to 50°C (5°F to 131°F) |
|
Relative Humidity |
0 - 90% non condensing |
|
Quality control system |
ISO 9001:2000, ISO 14002-2004 |
|
PHYSICAL | ||
Appearance |
224 x 255 x 80 |
|
500VA / 300W: 1.8kg ;1000VA /600W :2.0kg ; 2000VA / 1200W :2.5kg | ||
414*311*560(3pcs) | ||
500VA / 300W:7.4kg ; | ||
You can see the portable solar generator:
any questions pls feel free to contact me
Skype:capsolar4
