Specifications
1.High and stable conversion efficiency soalr panel2.25 year 80%, 10 year 90%
3.3 year power warranty
4,260/270/280/290/300W
300W High efficiency soalr panel for solar system
Characteristics
1) 300w solar panel with High reliability with guaranteed +/-3% output power
tolerance
2)The modules of 300w can withstand high wind-pressure, snow
loads and extreme temperatures
3) Bypass diodes to minimize power loss with shading
4) High and stable conversion efficiency to ensure the
highest quality
Quality and Safety
Industry leading power output warranty, 25 year 80%, 10 year 90%
power warranty and 3 year power warranty
ISO9001:2008 (Quality Management system) certified factory
Product Quality warranty & products Liability Insurance to
guarantee and user' benefits
Electrical Characteristics
| Module Type | OYD-260W | OYD-270W | OYD-280W | OYD-290W | OYD-300W |
| Maximum Power at ST(Pmax)W | 260W | 270W | 280W | 290W | 300W |
| Maximum Power Voltage(Vmp)V | 36/18 | 36/18 | 36/18 | 36/18 | 36/18 |
| Maximum Power Current(Imp)A | 7.2/14.4 | 7.5/15 | 7.77/15.55 | 8.05/16.11 | 8.33/16.66 |
| Open Circuit Voltage(Voc)V | 39.15/19.1 | 39.2/19.3 | 39.3/19.4 | 39.3/19.4 | 39.6/19.8 |
| Short Circuit Current(Isc)A | 7.8/15.6 | 8.03/16.05 | 8.13/16.26 | 8.86/17.72 | 9.16/18.33 |
| Cell Efficiency(%) | 15.57% | 16.5% | 16.7% | 17.3% | 18.1% |
| Module Efficiency(%) | 14.8% | 15.4% | 15.9% | 16.5% | 17.2% |
| Operating Temperature°C | -40°C to +85°C | ||||
| Maximum system voltage | 1000V(IEC)DC | ||||
| Power tolerance | +-3% | ||||
| Temperature coefficients of Pmax | -0.45%/°C | ||||
| Temperature coefficients of Voc | -0.27%/°C | ||||
| Temperature coefficients of Isc | 0.05%/°C | ||||
| Weight(kg) | 25.5 | ||||
| Number of cell(pcs) | 6*12 | ||||
| Dimensions(mm) | 1920*1000*50/35 | ||||
the solar panel is importtant part of the solar system:
Any questions please feel free to contact me
Skype:capsolar4
