Specifications
high quality bag dust collectorhigh efficiency and reliable operation
competitive price
ISO9001 CE
FD Compressed air puring surface dust collector
FD series of dust collector realizes automatic and continuous cleaning by compressed air,stable pressure difference gives the
machine safe running condition,Compared to FS series of dust collector,its cost is lower,cleaning pulse is controlled by electric
by pneumatic.Cleaning time and interval can be add justed.
Structure
The shell of filter is welded by using steel plates,a good sealing door ensures the dust air come into purifying cabinet.The filter is
composed of filter bags and tensioning brachet.it is very convenient to replace bags by opening the front door
The special components of clearing device
Nuzzle with easy-discharge
Film valve
Valve control unit
Compress air box
Dust collecting components
1.Filter cover 2.waste gas guiding input 3.Dust collecting hopper 4.Spiral transfer 5.Dust exhaust valve 6.Platform and ladder
Technical parameter
Type |
Amount of filtering bag(piece) |
Filtering area(m²) |
Width(mm) |
Wind capacity treatment(m³/h) |
FD601 |
72 |
108 |
1150 |
6500-13000 |
FD610 |
108 |
162 |
1630 |
9700-19500 |
FD602 |
144 |
216 |
2198 |
13000-26000 |
FD611 |
180 |
270 |
2678 |
16500-32500 |
FD620 |
216 |
324 |
3158 |
19500-39000 |
FD612 |
252 |
378 |
3726 |
22700-45400 |
FD621 |
288 |
432 |
4206 |
26000-52000 |
FD630 |
324 |
486 |
4686 |
30000-60000 |
FD622 |
360 |
540 |
5254 |
33000-66000 |
FD631 |
396 |
594 |
5734 |
36000-72000 |
FD640 |
432 |
648 |
6214 |
39000-78000 |
FD632 |
468 |
702 |
6782 |
43000-86000 |
FD641 |
504 |
756 |
7262 |
45000-90000 |
FD650 |
540 |
810 |
7712 |
49000-98000 |
FD642 |
576 |
864 |
8310 |
52000-104000 |
FD651 |
612 |
918 |
8790 |
55000-110000 |
FD660 |
648 |
972 |
9270 |
58000-116000 |
FD652 |
684 |
1026 |
9838 |
61000-122000 |
FD661 |
720 |
1080 |
10318 |
65000-130000 |
FD670 |
756 |
1134 |
10798 |
68000-136000 |
FD662 |
792 |
1188 |
11336 |
71000-142000 |
FD671 |
828 |
1242 |
11846 |
75000-150000 |
FD680 |
864 |
1296 |
12326 |
78000-156000 |
FD672 |
900 |
1350 |
12894 |
81000-162000 |
FD681 |
936 |
1404 |
133374 |
84000-168000 |
FD690 |
972 |
1458 |
13854 |
87500-175000 |
FD682 |
1008 |
1512 |
14422 |
90000-180000 |
FD691 |
1044 |
1566 |
14902 |
94000-188000 |
Certifications
Production photoes
Trade Terms:
1.Payment:
1) Telegraphic Transfer (30% advance payment, balance before shipment)
2) Telegraphic Transfer (30% advance payment, balance against copy of documents)
3) Letter of Credit: at sight
2. Lead Time: 2 weeks after confirmed order
3. Delivery way: by sea
Our Services:
1. Reply your inquiry in 24 working hours.
2. Experienced staffs answer all your questions in fluent English.
3. Customized design is available. UEM&UBM are welcomed.
4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.
5. Special discount and protection of sales are provided to our distributor.
6. Professional factory: We are manufacturer, specializing in producing all kinds of machinery for more than 11 years,
competitive with good quantity.
7. Sample: We can send out sample for test in one week if the order quantity is big enough. But the shipment charges are
usually paid by your side, the charges will be rebounded when we have formal order.
8. As an honest seller, we always use superior raw material, advanced machines, skilled technicians to ensure our products
to be finished in high quality and stable feature. Welcome to contact us or visit our company.
Packing and transportation:
Wooden case, cardboards, polyfoam, plastic,or loose package by sea,in container.
