Shanghai Hong An Marine Co.Ltd. Is a company manufacturing yacht made of fiber-glass and other materials.With our yacht we bring you credible quality and fashion outlook. Our yacht could be used for multiple purpose, such as military, marine traffic management,tourist sight-seeing, flood rescue and marine products industry.We also sell all kinds of inboard and outboard engines(gasoline or diesel),imported yachts as well as yacht parts, marine oils and marine product.
MAIN FEATURES
LOA 8.84 m
Beam 6.70 m
Folded beam 2.55 m
Dismounted beam 2.50 m
Draft daggerboard up 0.30 m
Draft daggerboard down 1.52 m
Light weight 1 000 Kg
Berths 1 double + 3 single
Standing headroom 1.80 m
Engine outboard 9.8 hp
Water 25 L
Mast height 11.65 m
Mainsail surface 29.00 m2
Jib surface 16.00 m2
CE category C
CONSTRUCTION
Hulls, floats & beams: glassfiber (bi-axial 600 gr/m2) foam and epoxy resin, vacuum infusion process. 2 component paint outside, polyurethane paint inside.
Lexan polycarbonate windows.
COCKPIT
4 storage spaces under the seats, removable board aft the cockpit, 2 lockers in the backrests, 1 fitting for the table, 2 pushpits one with flagpole support, one 3 step folding bathing ladder, fixed ob engine bracket, compass with light .
RUDDER / DAGGERBOARD
Kick up composite rudder fixed on the transom, wooden tiller.
Composite daggerboard, 2 ropes to handle it coming back to the cockpit.
RIGGING
Glass/carbon pultrusion 11.65 m rotating mast and boom, both painted white. Lowering the mast device.
Mono-strand wire forestay and diamonds , shrouds in Vectran .
RUNNING RIGGING
Polyester mainsail sheet, 2 polyester jib sheets, Braid 32 mainsail halyard, Braid 32 jib halyard, Braid 32 spinnaker halyard, 1 polyester mainsail foot, 2 Braid 32 reefing lines, 2 polyester shroud purchases.
SAILS
Pentex Elvstrom jib, hanked, Pentex Elvstrom mainsail with 2 reefing lines .
DECK FITTINGS
Main hull : Carbon fibre bowsprit and Blue Hull
Aluminium folding struts, bow shroud plate, 1 towing Ubolt, stainless steel pulpit, 4 st. steel cleats, anchor locker, 2 vertical turning blocks for daggerboard manoeuvring, st. steel ball mast base, 2 jib tracks with cars , mast base blocks, 2 x 5 sheaves deck organisers, 2 x 4 clutches, 2 st. steel 2 speed self tailing Andersen ST 28 winches , 1 pair of inner st. steel shroud plate, 1 mainsail track with single toggle car, 1 pair of track end fitting with cleats.
On each float:
St . steel shroud plate, 3 inspection plates, 1 opening hatch, 3 Ubolts.
NAVIGATION LIGHTS
1 LED bicolour navigation light on pulpit , 1 stern navigation light.
COMPANIONWAY
1 sliding entrance hatch, 2 part wooden door, hatch locker , removable aluminium 3 steps companionway.
ELECTRICITY
Electrical panel with 8 switches, protection by fuses , 1 x 12 V plug, 1 x 75 Ah battery, cables, ignition switch.
NAVIGATION AREA
Chart table with opening chart storage space, 1 LED ceiling light .
SALOON
Pivoting table, antiskid floor, 2 settees with cushions, 4 storage spaces in the back rests, 2 single berths 200 x 70 cm, toilet separation curtain, water tank under the port seat with water intake , battery locker under the starboard seat, 1 LED ceiling light, 1 chemical toilet .
GALLEY
Stainless steel sink , hand pump, 2 storage spaces, 1 LED ceiling light, 1 through hull fitting with hose.
FORE CABIN
190 x 130 berth with cushions, large storage locker under the berth, 50 x 50 cm opening hatch, 1 LED ceiling light.
MISCELLANEOUS
1 single berth with mattress under the cockpit floor with LED ceiling light , 1 manual bilge pump , 2 winch handles, 1 speed wrench for the folding system bolts.
