Help CenterHydraulic Winch 10 Ton
Related Products
-
50 Ton Hydraulic Winch for Oilfield UsingUS$ 1,000 - 200,000MOQ: 1 Unit -
INI 50 kN 5 Ton Winch Hydraulic Truck WinchUS$ 1,000 - 200,000MOQ: 1 Unit
-
3.5 Ton Air Winch Small Hydraulic WinchUS$ 1,000 - 200,000MOQ: 1 Unit
-
Small Electric Winch, Mini Hoist With 220vUS$ 1,000 - 200,000MOQ: 1 Unit
-
Small Winch for Marine/MiningUS$ 1,000 - 200,000MOQ: 1 Unit
QJ5/120(B)-Fair winches
Specification
1.QJ series of air winches are powered by piston-type air motor.
2.They have the advantages of compact structure, light weight, safe and easy to operate
3.they are used for general lifting, hauling and other works in mines, oil fields, on shipboards and etc.
4.Standard:API Spec 7K "Specification for Drilling Equipment".
Model |
QJL0.5/40(A) |
QJ0.5/120(A) |
QJ1/100(A) |
QJ3/200(B) |
QJ5/120(B)-* |
QJ5/220(B) |
||
|
Air Pressure
|
MPa |
0.5-0.9 |
||||||
psi |
72-130 |
|||||||
|
Max. Pull
|
kN |
5 |
5 |
10 |
30 |
50 |
50 |
|
US ton |
0.55 |
0.55 |
1.1 |
3.3 |
5.5 |
5.5 |
||
|
Max. Line Speed
|
m/min |
12 |
24 |
12 |
35 |
20 |
12 |
|
ft/min |
39.3 |
78.6 |
39.3 |
114.8 |
65.6 |
34.3 |
||
|
Rope Storage
|
m |
40 |
120 |
100 |
200 |
120 |
220 |
|
ft |
131 |
393 |
328 |
656 |
393 |
720 |
||
|
Wire Rope Diameter
|
mm |
8 |
8 |
11 |
15.875 |
15.875 |
19 |
|
in |
5/16 |
5/16 |
7/16 |
5/8 |
5/8 |
3/4 |
||
|
Size
|
mm |
495×365×380 |
675×343×460 |
825×343×450 |
1340×940×985 |
1300×940×985 |
1360×890×750 |
|
in |
19.5×14.3×15 |
26.5×13.5×18 |
32.5×13.5×18 |
53×37×39 |
51×37×39 |
53. 5×35×29.5 |
||
|
Weight
|
Kg |
45 |
117 |
162 |
600 |
580 |
800 |
|
lb |
100 |
258 |
357 |
1320 |
1280 |
1760 |
||
Note:
1.A means the winch may be equipped with remote control device. B means the winch may be equipped with auto-brake device.
2.The above table shows the specifications for normal winches.
3,F- means the flange connection, L-means the screw connection,without L means plate connection
Beijing Ocean Renda Petroleum Equipment Co.,Ltd engaged in Petroleum Equipment already 10 years. We provide the Petroleum Equipment ,qualifield parts and service about the Petroleum Equipment. Our products get the API certificates. At present, our main market is in South America. Our company have established four overseas company in United States, Colombia , Mexico and Dubai.
