The DSJ38 Series Roping Winding Machine
The DSJ38 Series rope winding machine is a specialized device to releasewind steel rope. With it, the used rope can be rewound for movementreuse. It may also prevent the rope from twistingreduce the work load of workers in an automated way. This machine is also applicable to releasewind large cableswires.
According to user requirements, its power systems are available in pneumatic, electrical,hydraulic. The basic hydraulic model is equipped with hydraulic source; the improved hydraulic model carries only the operating system without power source. The hydraulicpneumatic types can both achieve infinitely variable speed adjustment. The electrical type consists of constant speed varietyinfinitely variable speed variety.
Notes on product model
DSJ 38
DSJ: rope winding machine
Maximum rope diameter: 38mm;
Type: hydraulic: Y (omitted for basic hydraulic type); electrical: D; electrical with adjustable speed: T; pneumatic: Q.
Number of drums: single: no identity; double (with rope guide): S; double (with rope guide) side small drum: C.
Variety identity
DSJ38 series rope winding machine technical parameters table 1
Model |
DSJ38Y |
DSJ38YS |
DSJ38Q |
||
Output speed (r/min) |
0-12 |
0-18 |
0-12 |
||
Output torque (Nm) |
10000 |
10000 |
10000 |
||
Working pressure (Mpa) |
16 |
16 |
0.8 |
||
Bearing weight (kg) |
8000 |
12000 |
8000 |
||
Sheave dimension |
Max. width (mm) |
1300 |
1640 |
1300 |
|
Max. outer diameter (mm) |
2200 |
2200 |
2200 |
||
Min. central hole diameter (mm) |
90 |
100 |
100 |
||
Dimension (mm) |
2630×1800×1625 |
3045×2050×1845 |
2800×1900×1625 |
||
Weight (kg) |
1000 |
1450 |
1500 |
||
DSJ38 series rope winding machine technical parameters table 2
Model |
DSJ38D |
DSJ38DS |
DSJ38DSC |
||
Power (kW) |
7.5 |
7.5 |
7.5 |
||
Output speed (r/min) |
11 |
11 |
11 |
||
Bearing weight (kg) |
10000 |
10000 |
10000 |
||
Sheave dimension |
Max. width (mm) |
1600 |
1600 |
1200 |
|
Max. outer diameter (mm) |
2200 |
2200 |
2200 |
||
Min. central hole diameter (mm) |
100 |
100 |
100 |
||
Dimension (mm) |
3200×1950×1880 |
4080×1950×1875 |
3200×1790×1880 |
||
Weight (kg) |
1000 |
1000 |
1000 |
||
