API Spec 16D BOP liquid control line
- 100 Meter / Meters per Month
- Beijing/Tianjin
- T/T
- ACJ1112 12V automotive computer board relay chip 5 pins
- CAT 1873875 187-3875 TRANSFORMER GP Seal-O-Ring C7 3508 3512 Caterpillar Spare parts
- CAT 3S9643 3S-9643 Seal-Lip Type Cat Caterpillar Industrial Engine 3406 3408 3512 3516
- Caterpillar 5014308 501-4308 CAT Cone-Bearing for Articulated Dump Truck Engine 735B 740B
- Caterpillar 1873875 187-3875 TRANSFORMER Seal-O-Ring CAT Excavator 336E 345E 349E
- CAT 6254517 625-4517 Hydraulic Cylinder Seal Kit Caterpillar Excavator 324 330 336D
Product Details
Place of Origin: | Hubei, China | Brand Name: | JINGBO | Model Number: | API SPEC 16D, API SPEC Q1 |
Product Description
Specifications
API Spec 16D BOP liquid control lineStandard:API Spec 16D ,API Spec Q1
Nominal Inner diameter: 1/4"--1 1/2"
high quality
BOP liquid control line
specification
1, Standard:API Spec 16D ,API Spec Q1
2, Nominal Inner diameter: 1/4"--1 1/2"
3,Blowout Preventer (BOP) Control Line is a kind of high-pressure, fire-resistant and heat-insulation hose assembly. It is also suitable for hydraulic transmission at high-temperature and flammable places
4,High molecular polymer jacket type, stainless steel armored jacket type and braided stainless steel wire jacket type are available.
technical parameters
Nominal Inner Dia. (mm) | O.D. of Hose Assembly (mm) | Operating Pressure (Mpa) | Min. Burst Pressure (Mpa) | Min. Bending Radius (mm) | Thread | Operating Time (Min) with Fire-resisting at 750°C | |
Normal | Limit | ||||||
6.3 | 24 | 35 | 105 | 130 | NPT LP | 5 | 25 |
26 | 70 | 175 | |||||
8 | 28 | 35 | 105 | 140 | |||
32 | 70 | 175 | |||||
10 | 30 | 35 | 105 | 160 | |||
34 | 70 | 175 | |||||
12.5 | 37 | 35 | 105 | 210 | |||
43 | 70 | 175 | |||||
16 | 41 | 35 | 105 | 260 | |||
47 | 70 | 175 | |||||
19 | 44 | 35 | 105 | 280 | |||
50 | 70 | 175 | |||||
22 | 47 | 35 | 105 | 320 | |||
53 | 70 | 175 | |||||
25 | 50 | 35 | 105 | 360 | |||
56 | 70 | 175 | |||||
31.5 | 56 | 35 | 105 | 460 | |||
62 | 70 | 175 | |||||
38 | 63 | 35 | 105 | 560 | |||
69 | 70 | 175 |
