Cola Production Line

Cola Production Line photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New, New
Place of Origin:
Jiangsu, China
Brand Name:
WINMARK
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Jiangsu, China
Brand Name WINMARK
Model Number DCGF
Type Other, Filling Machine, Filling Machine
Certification CE
Warranty ONE YEAR
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. cola production line
2. carbonated drink machine
3. PET bottle
4. full-auto 3 in 1 monoblock

cola production line

bottle filling machine

CSD bottling factory



It is used for filling carbonated drink in PET bottles or glass bottles. We can supply the whole line.



Characteristics:



1. The washing, filling and capping 3 kinds of jobs will be finished just by this one machine.

2. It is very convenient to change sizes of bottles by means of advanced bottleneck clamping & bottle suspending technology



3. Advanced programmable PLC is equipped to control the main machine.

4. Working speed can be adjusted by frequency conversion device.

5. Main electronic components are all from famous international enterprises



Main Technical Specifications:

Model:

DCGF18-18-6

DCGF24-24-8

DCGF32-32-10

DCGF40-40-12

Production Capacity:500ml

5000

8000

12000

15000

Suitable Bottle Standard:

round or square shaped bottle.

Polyester Bottle Standard: (mm)

Bottle Diameter:50-110   (Height):150-340mm

Suitable Cap Standard:

Plastic Screw Cap

Filling Precision:

≤±5mm

Filling Pressure:(Mpa)

0.15-0.35

0.15-0.35

0.15-0.35

0.15-0.35

Filling Pressure:(Mpa)

0.2-0.25

0.2-0.25

0.2-0.25

0.2-0.25

Power:(KW)

4

4.8

7.6

8.3

Overall Size:(mm)

2650×1900 ×2400

2900×2100
×2400

4100×2400
×2400

4550×2650
×2400

Total Weight: (kg)

3500

4500

5500

6500





Our technology from Taiwan and Germany,Our machine have good quality and competitive price,Hope cooperate with you!
