stainless steel cutting machine
XC-2540W waterjet cutting machine price
The technical parameters of used water jet cutting machine :
| PICTURES | DESCRIPTION | WOOD PACKAGE | |
| | High precission, High quality, Long life, Friendly Environmental working, no pollution, No material waste
| Extra cost added | |
| Z Lifting stroke | 150mm | ||
| Repositioning Accuracy | ±0.02mm | ||
| Lead screw | From Taiwan to ensure high-precision, stable drive and durable in use for fabrication of parts. | ||
| Lead rail | From Taiwan to ensure high-precision, stable drive and durable in use for fabrication of parts. | ||
| shield | Stainless Steel | ||
| Discretionary security protection | Super travel limit protection function | ||
| Special design of the shield for better waterproof and sandproof, which makes the machine durable in use and graceful in appearance. | |||
| system | windows W7, professional water cutting software: NC studio V9.30 | ||
| NC computer configuration | True colour LCD 17 inch(cpu: yonah 2.6GHz, RAM: 2G, mainboard: GUANMING 945, HDD: 320G, DVD, USB...) | ||
| Motor | AC servo motor from Taiwan | ||
| Drive | AC servo drive from Taiwan(TECO) | ||
| Others | Simply and convenient in operation | ||
| Max discharging capacity | 3.7L/MIN | ||
| Pressure control | The operating pressure can be adjusted manually at will and the cutting speed can be adjusted at will. | ||
| Filter system | Fine three-layer filter system makes higher degree of purity of the water for cutting: 5μ m/1μ m/0.45μ m, which highly prolong the service life of all parts of the high-pressure system. | ||
| Discretionary security protection system | OP Power-off protection for low-pressure system | ||
| High-pressure safety vavle equipped on high-pressure system, which has self-destruction safety for over pressurization | |||
| Electronic display and OP safety | |||
| The hydraulic system is equipped with oil temperature detecting PD, which will auto alarm when the oil temperature exceeds 60℃ | |||
| Thorough filter system and discretionary security protection system: double filter of the hydraulic system guarantees safety | |||
| The system has multiple alarm and safeguard, which will auto stop once there comes alarm. | |||
| The high-pressure pipe lines are solid cone seal, which is good in sealing and safe and reliable | |||
| Dynamic packing is equipped with high-pressure sealing ring made of imported high-strength nylon, which has service life of 400 hours. | |||
| Main motor power | 37KW | ||
| Hydraulic oils | Antiwear hydraulic oils 46#(ambient temperature 15-40℃) (Excluded) | ||
| High pressure water switch | Pneumatic valve, which makes moment open and moment(delayed) shut of the high pressure water | ||
| CNC miscellaneous functions makes autocontrol of the high pressure water | |||
| Blockage pressure can be adjusted at will and realizes drilling in low pressure | |||
| The quick-wear parts are easy to be replaced | |||
| Sand control valve | Self-absorption type sand handling | ||
| Pneumatic vavle overcomes sand blocking and breaking caused by magnetism of the solenoid vavle | |||
| Manual adjustment for sand flow | |||
| CNC miscellaneous functions makes autocontrol of ABRA | |||
| Sand hopper | Side-attached sand hopper | ||
| Side mounted window to watch consumption of ABRA, prompting the operation staff when to replenish sand | |||
| Max peassure | 380MPA | ||
| Cutting materials | Glass,Tile,Marble,Granite,Aluminum,Stainless Steel, etc | ||
| Cutting thickness | Max 100mm | ||
| Cutting speed | Accordingly | ||
Conventional packaging | Standard carton box or as your request. |
Delivery date | 15 days after received the deposit |
Shipping way | By sea or couriers |
The company starts from 20 years before, and his initial major is MOULD MARKING,And after that the company start production of engraving machine parts and whole machines, plastic parts injection, and etc.
Please be kindly noted that the company is one MANUFACTURER and not only a assembly place, as the company has workshop and Machinery equipments to produce small and big parts of engraving machine, and the company also supply the self-produced parts to MORE COPANIES that assemble ENGRAVING MACHINE from China and World.
And now the company mainly produce and supply the following products and service:
1. Mould making
2. Engraving machines (include Woodworking engraving machine, stone engraving machine, advertising engraving machine, laser engraving machine, metal engraving machine, waterjet cutting machine, etc.)
3. Engraving machine parts production and supplying
4. Plastic parts injection
With more years experience, techincal, and quality assurance, and based on more years production basis, the company welcome and glad to cooperate with customers all over the world. Mutual benefits based on friendly cooperation is the company's aim.
REMAKRS
NOTE:
1. All prices are based on FOB QINGDAO basis.
2. MOQ is 1pc
3. Payment: 40%-100% tt deposit, and if have balance should be paid before shipment.
4. Delivery: Around 25-35 days.
5. All prices are subject to final confirmations.
6. Main specs change without further notice.
