Mini Size and High Precission XC-1010W Waterjet Cutting Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
XINGCHEN OR OEM
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Super Mini Size XC-0505W Water Jet Cutting MachineUS$ 1,111 - 11,111MOQ: 1 Set -
Multi-fuction CNC Metal Waterjet Cutting Machine for Marble/granite/foamUS$ 30,000 - 50,000MOQ: 1 Set
-
China High Quality CNC Water Jet Cutting Machine for Marble/granite/foam/stone Grooving Water Jet Cutting MachineUS$ 30,000 - 50,000MOQ: 1 Set
-
New Design CNC Waterjet Cutting Machine Marble/granite/foam/stone Grooving Water Jet Cutting MachineUS$ 30,000 - 50,000MOQ: 1 Set
-
High Precision Cnc Processing Center Water Jet Cutting Machines PricesUS$ 30,000 - 50,000MOQ: 1 Set
Condition
New
Place of Origin
Shandong, China
Brand Name
XINGCHEN OR OEM
Model Number
XC-1010W
Voltage
380
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
mini size and high precission XC-1010W waterjet cutting machine
Product Description
| Range of work | 1000×1000mm | |||
| Z Lifting stroke | 150mm | |||
| Repositioning Accuracy | ±0.02mm | |||
| X max travel speed | 6000mm/min | |||
| Y max travel speed | 6000mm/min | |||
| Z max travel speed | 1000mm/min | |||
| Cutting Accuracy | ±0.01mm~±0.02mm (According to cutting speed and material) | |||
| Lead screw | TBI From Taiwan to ensure high-precision, stable drive and durable in use for fabrication of parts. | |||
| Lead rail | HINWIN From Taiwan to ensure high-precision, stable drive and durable in use for fabrication of parts. | |||
| shield | Stainless Steel | |||
| Discretionary security protection | Super travel limit protection function | |||
| Special design of the shield for better waterproof and sandproof, which makes the machine durable in use and graceful in appearance. | ||||
| system | windows W7, professional water cutting software: NC studio V9.30 | |||
| NC computer configuration | True colour LCD 17 inch(cpu: yonah 2.6GHz, RAM: 2G, mainboard: GUANMING 945, HDD: 320G, DVD, USB...) | |||
| Motor | AC servo motor from Taiwan | |||
| Drive | AC servo drive from Taiwan(TECO) | |||
| Others | Simply and convenient in operation | |||
| Max discharging capacity | 3.7L/MIN | |||
| Pressure control | The operating pressure can be adjusted manually at will and the cutting speed can be adjusted at will. |
|||
| Filter system | Fine three-layer filter system makes higher degree of purity of the water for cutting: 5μ m/1μ m/0.45μ m, which highly prolong the service life of all parts of the high-pressure system. | |||
| Discretionary security protection system | OP Power-off protection for low-pressure system | |||
| High-pressure safety vavle equipped on high-pressure system, which has self-destruction safety for over pressurization | ||||
| Electronic display and OP safety | ||||
| The hydraulic system is equipped with oil temperature detecting PD, which will auto alarm when the oil temperature exceeds 60℃ | ||||
| Thorough filter system and discretionary security protection system: double filter of the hydraulic system guarantees safety | ||||
| The system has multiple alarm and safeguard, which will auto stop once there comes alarm. | ||||
| The high-pressure pipe lines are solid cone seal, which is good in sealing and safe and reliable | ||||
| Dynamic packing is equipped with high-pressure sealing ring made of imported high-strength nylon, which has service life of 400 hours. | ||||
| Main motor power | 37KW | |||
| Hydraulic oils | Antiwear hydraulic oils 46#(ambient temperature 15-40℃) (Excluded) | |||
| High pressure water switch | Pneumatic valve, which makes moment open and moment(delayed) shut of the high pressure water | |||
| CNC miscellaneous functions makes autocontrol of the high pressure water | ||||
| Blockage pressure can be adjusted at will and realizes drilling in low pressure | ||||
| The quick-wear parts are easy to be replaced | ||||
| Sand control valve | Self-absorption type sand handling | |||
| Pneumatic vavle overcomes sand blocking and breaking caused by magnetism of the solenoid vavle | ||||
| Manual adjustment for sand flow | ||||
| CNC miscellaneous functions makes autocontrol of ABRA | ||||
| Sand hopper | Side-attached sand hopper | |||
| Side mounted window to watch consumption of ABRA, prompting the operation staff when to replenish sand | ||||
| Max peassure | 420MPA | |||
| Voltage | 220/380/415V AC, 50/60HZ | |||
| Cutting materials | Glass,Tile,Marble,Granite,Aluminum,Stainless Steel, etc | |||
| Cutting thickness | Max 100mm | |||
| Cutting speed | Accordingly (According to material, thickness, etc) | |||
