solar house solar system solar modules
We are manufacturer of high quality
We have over 19 years’ experienceof manufacturing outdoor lighting and solar systems. We own the serious machine for the whole set making process . You can find our Solar LED Street Light and solar modules all over the China and they are also installed in north America, south America, Africa, Europe and etc.
| Item No. | XKK-SS-1 | |
| System Basic Information | Solar Panel Rated Output Power | 10KW |
| Suitable for Max Daily Power Consumption | 33KWH | |
| Rated Output AC Capacity | 10KW | |
| Solar panel | ||
| Type | Crystalline Silicon PV Module, A-class | 40pcs |
| Max Power | 250W | |
| Vmp | 30.5V | |
| Size | 1655*992*45mm | |
| Weight | 22.5kg/pc | |
| 25 years power output guarantee (Note: 2pcs panels connect in series) | ||
| PV Array Combiner | ||
| 1. Wide range of DC input voltage2. IP65 guard level, suitable for outdoor3. Reliable thunderstorm & surge protection4. Multiple PV strings inputs (10 strings) | 1 pc | |
| Controller | ||
| Voltage | 96V | 1pc |
| Current | 100A | |
| Warranty | 1 year | |
| PWM high-efficiency charging controller, LED display, intelligent control; Temperature compensation, various protections. | ||
| Circuit Breaker | Used for protection of controller, installed between PV array combiner and controller | 1pc |
| Inverter | ||
| Input Voltage | DC96V | 1set |
| Output Voltage | AC220V 1-phase | |
| Frequency | 50/60Hz | |
| Efficiency | 90% | |
| Note: This inverter provides grid power switch and battery charging functions. | ||
| Battery | ||
| Capacities | 12V/200AH per piece | 32pcs |
| Service life | 5 to 6 years | |
| Warranty | 3 years | |
| Solar panel rack | Flat-roof type mounting rack, steel material, anti-rust treatment | 1 set |
| (Other types of racks can be customized as per client's requirement) | ||
| Cable | 60m | |
| Connectors | 3-terminal connectors, used for panels connection in parallel | 10 pcs |
Working Principle:
This is an off-grid system which uses batteries to store the solar energy, at the same time, the system can be connected with the grid for utilization of grid power. The system uses battery power in priority, but when sunshine is not so good or loads consumption is too big which caused the battery power inadequacy, then the system can switch automatically to grid power supply. Meanwhile, the system can charge the batteries with grid power until batteries are fully charged. Then the system will switch back to battery power supply.
Why Us
One-stop Service
You can find solutions for almost all outdoor lighting from us, like street lighting, square lighting, landscape lighting, traffic lighting and commercial lighting and so on.
Vertically Integrated Production System
You will enjoy high-quality product with cost-effective price from us because we manufacture most of the main components from LED source, light fixture, solar panel, pole and even painting powder to control the cost and quality.
18 Years Manufacturing Experience
Since 1998, we have started manufacturing street lighting. The 15 years’ experiences have been a persuasive insurance for us to offer reliable products.
Large Factory with Complete Facility
We have 400 staffs with factory area 6000 m2. We also equipped with complete production and testing equipments, such as Steel Pole Rolling Machine, Spray Machine, Pressure Machine, Integrating Sphere, Lighting Simulating Machine and Weather-ability Testing Machines, etc . .
Advanced Technology
Our 60 experienced engineering team work with the PV institute of Shanghai FUDAN University , Shenzhen Foxconn to R&D outdoor lighting products. We have obtained over 20 national patents and built our own brand LUYOU.
Cost Efficiency
Manufacturing main components to save cost. BAODE manufactures the solar panel, light fixture and pole to control the cost and quality.
Factory outlet. There’s no middleman between the manufacturer BAODE and domestic and oversea buyers.
1. Price Term: EXW, FOB, CFR or CIF.
- The price includes pole shaft, base plate, crossarm and anchor bolt.
- Shipping seaport: Shanghai Seaport.
- Please provide drawings if you have so that we can calculate the accurate price for you.
- We also provide design according to your requests, if you don't have drawings.
2. MOQ: 1 set for Customized.
3. Payment Term: Typically 30% by T/T as deposit, balance by T/T or L/C at sight before shipment. Other payment way can be negotiated.
4. Delivery Time: 2 weeks per container after PO/drawing/prepayment confirmed.
|
