Magnesium(Mg) Alloy AZ63A

Name: Magnesium(Mg) Alloy AZ63A
Brand: chmetal
SKU: 109358391
Availability: InStock

Negotiable MOQ: 20 Tons (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shaanxi, China

Brand Name:

chmetal

Model Number:

Magnesium Alloy

Hunan Famous Trading Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China main port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shaanxi, China

Brand Name chmetal

Model Number Magnesium Alloy

Application industry

Material AZ91B

Chemical Composition Al,Zn,Mn,Si,Cu,Ni,Fe,Be,Mg

Specifications

CIQ, SGS, ISO quality certificate.
15 years factory experience in Mg Alloy.

Our Brand:

Specification:

Magnesium Alloy
ITEM	Al	Zn	Mn	Si≤	Cu≤	Ni≤	Fe≤	Be	Mg
AZ91D	8.5-9.5	0.45-0.9	0.17-0.40	0.05	0.025	0.001	0.004	0.0005-0.003	Bal
AM60B	5.6-6.4	0.20	0.26-0.50	0.05	0.008	0.001	0.004	0.0005-0.003	Bal
AM50A	4.5-5.3	0.20	0.28-0.50	0.05	0.008	0.001	0.004	0.0005-0.003	Bal
AZ63A	5.5-6.5	2.7-3.3	0.15-0.35	0.05	0.015	0.001	0.005	0.0005-0.0015	Bal
AZ91A	8.5-9.5	0.45-0.9	0.15-0.40	0.20	0.08	0.010	/	/	Bal
AZ91B	8.5-9.5	0.45-0.9	0.15-0.40	0.20	0.25	0.010	/	/	Bal
AZ91C	8.3-9.2	0.45-0.9	0.15-0.35	0.20	0.08	0.010	/	/	Bal
AZ31B	2.5-3.5	0.6-1.4	0.2-1.0	0.1	0.01	0.005	0.0005	/	Bal
AZ81A	7.2-8.0	0.5-0.9	0.15-0.35	0.2	0.08	0.01	/	0.0005-0.0015	Bal
AM100A	9.4-10.6	0.2	0.13-0.35	0.2	0.08	0.01	0.004	/	Bal
AS41B	3.7-4.8	0.1	0.35-0.6	0.6-1.4	0.015	0.001	0.0035	0.0005-0.003	Bal
ZC63A	0.2	5.5-6.5	0.25-0.75	0.2	2.4-3.0	0.001	0.05	/	Bal
MOQ:20MT Delivery: prompt shipment Packing: ON MAGNESIUM PALLET OR WOODEN PALLET

The mechanical properties at room temperature:

Electromagnetic shielding:

Method	Conductive Layer Thickness(μm)	Resistivity (Ohm/sq.)	Shielding Effectiveness(dB)
Zinc Arc Spray/Plastics	12~25	0.03	50~60
Zinc Flame Spray / Plastic	25	4.0	50~60
Nickel-Acrylic Paint/Plastics	50	0.5~2.0	30~75
Cathode Sputtering Plastics	0.75	2.5	70~90
Electroplating Plastics	0.75	0.1	85
Ion Plating Plastics	1.0	0.01	50
Vacuum Metalizing Plastics	1.25	5~10	50~70
Conductive Plastics	2000~3000	75~100	50
AZ91D-Mg Al Alloy	800~1500	0.04	90~110
