High Effiency 220VDC Three Phase Pure Sine Wave Inverter

High Effiency 220VDC Three Phase Pure Sine Wave Inverter thumbnail-1
High Effiency 220VDC Three Phase Pure Sine Wave Inverter photo-1
US$ 220 - 800 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shaanxi, China
Brand Name:
ACSOON
Model Number:
AND220 Seires output single phase
Contact Supplier Request Quote Chat Now
Xian Jerrystar Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port in China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shaanxi, China
Brand Name ACSOON
Model Number AND220 Seires output single phase
Output Power 1 - 200KW
Output Type Single
Size Pls refer below list in specification
Weight Pls refer below list in specification
Input Voltage 220VDC+-20%
Output Voltage 220VAC/120VAC
Type DC/AC Inverters
Output Frequency 50Hz,60Hz
Output Current As per your request

Specifications

pure sine wave inverter
1.pure sine wave O/P
2.IGBT/SPWM
3.Double isolation,safe and reliable
4.Protection function

High effiency 220VDC three phase pure sine wave inverter

DC TO AC inverter pure sine wave line

ACSOON inverter are proven, easy-to-use solutions for delivering AC power from batteries orother DC source like solar power source. With the rugged design and reliable performance make themthe smart choice for utilities or industrial environments where power transients andsurges are a concern. Clean .low-distortion sine wave output make them ideal powering sensitiveelectronics such as microprocessor-based instrument and PLC’s produces AC power from yourDC source or battery in zero time or in 4 second for online model. The inverters keep the incomingpower providing a high quality sinewave output with very low distortion.

For off-line model the inverter shut down and continue working in 4 seconds and providinga high quality sinewave output with very low distortion in the event of inverter failure unitwill BY-PASS AC input

AC preferred option is available. For the details please consult factory.

 Features:

1: The pure sine wave output .low output THD

2:IGBT/pact size lower noise high reliability

3: Double isolation of the input and output unit .safe and reliable

4: Protection: overcurrent,overvoltage,overheat,overload protection and automatic warning device.







APPLICATION:



ACSOON INV(DC to AC INVERTER) are widely used in various: ELECTRICITY,INDUSTRIAL EQUIPMENT, SATACOM(statellite communications),Military GPS,MEDICAL TREATMENT AMBULANCE,PATROL WAGON,SHIPPINGS,COLAR ENERGY,WIND ENGERGY GENERATION fields.



Inverter----DC TO AC Inverter----Pure sine wave inverter
Input 220VDC,output Three phase
Model(AND220-) 30030 30060 30100 30150 30200 30300
Capacity 3KVA 6KVA 10KVA 15KVA 20KVA 30KVA
Input Voltage 220VDC+-20%
Output Voltage 220VAC/120VAC
Frequency 50Hz,60Hz/400Hz
Frequency
stability		 +-0.5%
Response 20ms
Distortion Pure Sine Wave THD<3%(Measured at full load)
Overload Capacity 120%
Power factor 0.8
Crest factor 3:1
Phase 3 Phase
Communicate Interface RS232/485
Theory IGBT/SPWM(Infineon or mitsumishi module)
Protection Double Protection Input low voltage protection,Overvoltage proetction,overload protection,overcurrent protection,Thermal Protection,Short Circuit Protection,reverse voltage protection
Display LED Display Indicating on power on/off,indicating on invertering(Green)
Indicating on power voltage & over current,over heat(Red)
Working Condition Temperature minus 10 to plus 50 degree
Humidity 20-95%
Noise <50db within 1 meter
Demensions(mm) Approx 380*530*670 600*400*950 550*600*1000
Weight(kg) Approx Pending,pls consult factory Pending,pls consult factory Pending,pls consult factory






Packaging & Shipping

  pure sine wave inverter

Package:exported protective case,according to actual size and its weight to use wooden case or carton;

Lead time:It will take7-10 working days for the production;

High effiency 220VDC three phase pure sine wave inverter


Our Services

  pure sine wave inverter

1.OED/ODM Service provided;

2.Excellent sales Service;

3.Product guarantee service;

4.Escrow payment is available;


Company Information



Xi’an Jerrystar Instrument Co.,Ltd is a professional corporate enterprise which is specialized in developing & designing, manufacturing, trading and after service for electrical power supply. We dedicated in research and development the supreme quality and for the goal of “first grade power source and create ACSOON brand to the entire world.



We main producing  pure sine wave inverter,solar power inverter, dc ac power inverter, dc to ac inverter, frequency inverter,frequency converter,voltage regulator,stabilizer,ac power source and etc power supply system.



With the feedback from marketing and different requirement, ACSOON Power Source devote to research and development to create new product continuously and have various kind of specifications for choosing. Extensively used in:

GOVERNMENT ORGANIZATION,MESSAGE, HOME APPLIANCE,AVIATION,AEROSPACE,SHIPPING BUILDING(MARINE),RAILWAY,TRANSPORTATION,COMMUNICATION,BROADCASTING AND TV,MEDICAL TREATMENT,FINANCIAL,QUALITY INSPECTION,INDUSTRY,LABORATY and etc civil and military each field to provide the security and reliability, stability and high quality power source with clients home and abroad.



And our factory is approve by ISO9001 and obtained all series product design patents.

We are building a new factory covered up to 10,000 square meters.



ACSOON Power Source, Military quality, Excellent performance,your most reliable power source!
