Best quality 4 wheels mobile trailer diesel generator set 10-500KW
- 400 Set / Sets per Month
- Qingdao
- T/T
Product Details
Place of Origin: | Shandong, China | Brand Name: | SUPERMALY | Model Number: | SP10GFT-SP500GFT |
Output Type: | AC Three Phase | Speed: | 1500/1800RPM | Frequency: | 50/60HZ |
Rated Power: | 10-500KW | Rated Voltage: | 220V, 400V, 415V, 480V | Rated Current: | 18-900A |
Product Description
trailer diesel generator feature
1) Trailer diesel generator is developed to meet with the demand of market. They both have the character of easily portable, flexible operation, safe, reliable, standard –complied noises and good sealing ect. They enjoy the wide application in many vital circumstances, such as postage, electrical, hotel and the industrial and mining enterprises ect.
2) Trailer diesel generator has perfect all-weather service property and the outside steel material features preferable corrosion
3) Trailer diesel generator with Cummins engine, Deutz engine, Steyr engine, Volvo engine, Lovol engine, Yangdong and China brand.
4)Trailer diesel generator with alternator Stamford, Lerory Somer, Mathron, Engga and Chinese brand alternator
5) Noise level: below to 75dB by 7m distance
6) 8-24hrs operation base tank
7) Key start / auto start
specification of 24kw trailer diesel generator | |||
Genset Model | Trailer Type | SC25GFT | |
Prime Power(kW) | 25 | ||
Standby Power(kW) | 27.5 | ||
Rated current(A) | 45 | ||
Overall Size(mm) | Length(mm) | 2900 | |
Width(mm) | 1620 | ||
Height(mm) | 2000 | ||
Gross Weight(kg) | 1200 | ||
Diesel Engine | Model | 4BT3.9-G1 | |
Type | water-cooled,4-stroke,direct injection,wet cylinder liner | ||
Rated Power(kW) | 36 | ||
Rated speed(RPM) | 1500 | ||
Intake Type | Turbocharged | ||
No.of Cylinder | 4.L | ||
Bore x Stroke(mm) | 102*120 | ||
Compression ratio | 16.5:1 | ||
Exhaust Temperature(°C) | 475 | ||
Lub oil Capacity(L) | 11 | ||
Rated Fuel Consumption(L/h) | 8.3 (100% load) | ||
Displacement(L) | 3.9 | ||
Starting method | DC 12V Electric motor | ||
Governing Type | Mechanical governor | ||
Alternator | Brand | Stamford technology alternator | |
Model | 184G | ||
Rated Power(kW) | 25 | ||
Power Efficiency | 93.90% | ||
Excitation Type | Brushless | ||
Insulation Class | H |
