Specifications
Konics High-accuracy temperature transmitter kt-502h remote monitoring Koreaauthorized konics distributor China
Korea Konics
Konics High-accuracy temperature transmitter kt-502h remote monitoring Korea
authorized konics distributor China
Korea Konics QQ:1904640213 Remote monitoring is available as high-accuracy temperature transmitter of multi input range.
* Input : B,R,S,K,J,E,T,N,RTD,mV,V, mA
* Measuring cycle : 1Sec
* Input resistance : 1F.S
* Signal resistance : RTD Type 10Ω/Line, Other 300Ω
* CMRR : Min. 140dB
* NMRR : Min. 40dB * Filter : None, Fir, 4AVG, 8AVG, 16AVG
* Output : 2wire 4~20mA DC (Low limit : 3.8Ma,Upper limit : 20.8mA)
* Isolation : 100F.S more with 500VDC (Input to output)
* Dielectric strength : 1000VAC 1minute (Input to output)
* Load limit : R=(Vsp-15)/0.021Ω
* Step response time : min 1sec
* Degree of protection : IP65
* Indicator : 4Digit LCD Indicator
* Power supply :C15~35V DC
* Material of case : Al Die casting (Ex DⅡ CT6)
* Weight : 2.3kg
* Auto returning time : 1.5sec
* Turn on time : min 10sec
