50kva AC marine generator set with factory price
- 500 Set / Sets per Month
- Qingdao
- T/T
You May Like
-
50kva marine generator set for sale with CE certificate
-
Good performance 44kw deutz marine generator set for sale
-
5kw marine generator set with Deutz (engine)/Ricardo
-
50kw marine generator set with Ricardo engine
-
50kw marine generator set with Deutz engine
-
15kw/18kva-800kw/1000kva marine generator with Ricardo or cummins (engine) brands
Product Details
Place of Origin | Shandong, China | Brand Name | SUPERMALY | |
Model Number | SD40GFC | Output Type | AC Three Phase | |
Speed | 1500rpm/1800rpm | Frequency | 50HZ/60HZ | |
Rated Power | 40KW/50kva | Rated Voltage | 220V/230V/380V/400V | |
Rated Current | 72A |
Product Description
ac marine diesel generator Specifications
1. The power range of marine diesel engines gearbox is 10-1000kW and its speed range is 1500-2500r/min, Low fuel consumption
Main advantages of marine diesel engines gearbox:
1. its speed range is 1500-2500r/min, Low fuel consumption,The minimum fuel consumption of
226B engine is 198g/kW.h. it's fuel consumption curve is very flat. It has
good economy under common working condition.Reliable operation
2. WD615 series marine diesel engine has been developed since 1989. It was
supplemented with inter-cooler, exchanger for seawater and freshwater,
monitor and seawater pump
3. WD618 marine engine, according to the requirement of vessels, WD618C
series marine diesel engines has the merits of large power backup, low fuel
consumption, low emission, high reliability, easy operation and convenient
maintenance. The output ranges from 150-275kW with a speed of
1500-2150r/min. It can be widely used in various kinds of vessels. MB270A,
300, D300 series gear boxes can be applied to the engine sets with the
speed ratio from 2:1 - 7:1
4. For marine diesel engines 6170C, output ranges from 258-330kW for engines
of 1000 r/min, and 258-382kW for engines of 1200r/min, 258-426kW for
1350r/min and 258-456kW for 1500r/min
5. The R6160 series marine engine, designed out of brand new conception, has
reached internationally advanced position.The speed of R6160 series is
1000r/min with a power range of 164kW(223hp)-255kW(350hp)
genset model | diesel engine | alternator | |||
model | prime power(kW) | speed | model | ||
15CS | 295C | 15.6 | 2000 | 16A | 3.5:1 |
19CS | 2100C | 16.5 | 2000 | 16A | 3.5:1 |
30CS | 4100C | 35 | 2000 | J16A | 3.5:1 |
33CS | R4105C | 43 | 2000 | MA142 | 4:1 |
40CS | R4105ZC | 58 | 2000 | MA142 | 4:1 |
65CS | R6105C | 65 | 2000 | MB170 | 4:1 |
88CS | R6105ZC | 88 | 2000 | MB170 | 4:1 |
110CS | 6105AZLC | 110 | 1500 | 135A | |
135CS | R6105IZLC | 135 | 1500 | 135A | |
169CS2 | 6126ZLC2 | 176 | 1800 | FD135 | 2:1 |
197CS4 | 6126ZLC5 | 205 | 2100 | FD135 | 4:1 |
211CS5 | 6126ZLC6 | 225 | 2100 | 300 | 5:1 |
GENSET - 50 Hz at 1500 RPM | ENGINE DETAILS | ALTERNATOR | APPROXIMATE DIMENSIONS | ||||||||||||||
Open Type | Open Type | ||||||||||||||||
Model |
PRIME | STANDBY | Model | R/Power | Type | No. of | Arrange. | Fuel | MARATHON | Length | Width | Height | Gross | Packed | |||
kW | kVA | kW | kVA | kW | Hp | Nat/asp | Cyls. | of Cyls. | Cons. | Made in China | (A) | (B) | (C) | Weight | Volume | ||
Made in China | or Turbo | Inline/Vee | ltrs/h | Model | mm | mm | mm | Kg | m3 | ||||||||
SH15GFC | 15 | 18.75 | 16.5 | 20.625 | 495D3 | 26.5 | 36.04 | Nat/asp | 4L | Inline | 4.84 | MP-H-15 | 1850 | 770 | 1450 | 810 | 2.07 |
SH20GFC | 20 | 25 | 22 | 27.5 | 495D3 | 26.5 | 36.04 | Nat/asp | 4L | Inline | 6.45 | MP-H-20 | 1850 | 770 | 1450 | 825 | 2.07 |
SH24GFC | 24 | 30 | 26.4 | 33 | K4100D3 | 30.1 | 40.936 | Nat/asp | 4L | Inline | 7.74 | MP-H-24 | 1850 | 770 | 1450 | 850 | 2.07 |
SH30GFC | 30 | 37.5 | 33 | 41.25 | R4105D4 | 56 | 76.16 | Nat/asp | 4L | Inline | 8.66 | MP-H-30 | 2000 | 770 | 1450 | 920 | 2.23 |
SH40GFC | 40 | 50 | 44 | 55 | R4105ZD4 | 56 | 76.16 | Turbo | 4L | Inline | 11.55 | MP-H-40 | 2000 | 770 | 1430 | 960 | 2.20 |
SH50GFC | 50 | 62.5 | 55 | 68.75 | R6105D4 | 84 | 114.24 | Nat/asp | 6L | Inline | 14.00 | MP-H-50 | 2300 | 770 | 1450 | 1100 | 2.57 |
SH64GFC | 64 | 80 | 70.4 | 88 | R6105ZD4 | 84 | 114.24 | Turbo | 6L | Inline | 17.92 | MP-H-64 | 2400 | 770 | 1600 | 1230 | 2.96 |
SH75GFC | 75 | 93.75 | 82.5 | 103.125 | R6105AZLD4 | 110 | 149.6 | Turbo | 6L | Inline | 21.00 | MP-H-70 | 2400 | 770 | 1600 | 1300 | 2.96 |
SH90GFC | 90 | 112.5 | 99 | 123.75 | R6105AZLD4 | 110 | 149.6 | Turbo | 6L | Inline | 24.53 | MP-H-90 | 2400 | 770 | 1600 | 1360 | 2.96 |
ac marine diesel generator INTRODUCTION
Marine diesel generator set choose the famours brand such as shipboard diesel engine of Perkins(engine),Ricardo(engine) and Cummins(engine) as the dynamic force.The engine in good dynamic performance,safty and reliable.The marine generator set is widely used as prime or standby power supply in all kinds of passenger ship,cargo ship,fisher.
IF YOU HAVE ANY QUESTIONS,,PLZ EMAIL OR ADD ME ON SKYPE:guaicc521.
1. we supply spare parts during the whole service life.
2. one year warranty. and we are manufacturer with 2 factories in weifang city, after-sale service guaranteed.
3. open frame type/ silent type/ weatherproof type/ trailer/ container type, at your option.
4.Engine brand can be Cummins, Deutz, Lovol, Ricardo
5. Decades’ years of manufacturing and exporting experience
6. Adopt International quality standards, to meet high quality requirement
7. Good reputation for Reliable quality & Reasonable price
8. Strong technical support
9. Advanced production line with skilled workers
