UL approved SSR Crydom H12WD4850PG solid state relay
- 0 per Month
You May Like
-
PCB mount SSR Crydom solid state relay model CX240D5 DC control SSR
-
DIN rail mount SSR Crydom solid state relay model DRA1-CX240D5 DC control SSR
-
GN 84137870 DC SSR Crouzet solid state relay model 84137870
-
Panel Mount SSR AC Output Crydom SSR CWD4890P Crydom solid state relay
-
CMXE200D3 SSR Crydom miniature solid state relay DC solid state relay
-
Crydom SSR XBP4025C Crydom solid state relay panel mount SSR
Product Details
| Place of Origin | Mexico | Brand Name | CRYDOM | |
| Model Number | H12WD4850PG | Theory | Solid State Relay | |
| Usage | General Purpose | Size | Miniature | |
| Protect Feature | Sealed | Contact Load | Low Power |
Product Description
Specifications
UL approved SSR Crydom H12WD4850PG solid state relayCrydom SSR models:
H12WD48125, 4-32 VDC, 125 Amps, 48-660 VAC
H12WD4850
UL approved SSR Crydom H12WD4850PG solid state relay
Crydom SSR models:
H12WD48125, 4-32 VDC, 125 Amps, 48-660 VAC
H12WD48125-10, 4-32 VDC, 125 Amps, 48-660 VAC
H12WD4825, 4-32 VDC, 25 Amps, 48-660 VAC
H12WD4825-10, 4-32 VDC, 25 Amps, 48-660 VAC
H12WD4850, 4-32 VDC, 50 Amps, 48-660 VAC
H12WD4850-10, 4-32 VDC, 50 Amps, 48-660 VAC
H12WD4875, 4-32 VDC, 75 Amps, 48-660 VAC
H12WD4875-10, 4-32 VDC, 75 Amps, 48-660 VAC
H12WD4890, 4-32 VDC, 90 Amps, 48-660 VAC
H12WD4890-10, 4-32 VDC, 90 Amps, 48-660 VAC
Attribute Type Attribute Value
Product Index Zero Voltage
Control Voltage 4 → 32Vdc
Load Voltage 48 → 660Vac
Maximum Switching Current 50A
Mounting Type Surface
Off State Leakage Current 1mA
Release Voltage 1V(dc)
Series H12
Surge Current Peak 250A
Terminal Type Screw; Saddle Clamp
Width 45.7mm
Max On-state Voltage Drop At Rated A 1.6V
Maximum Turn Off Time 10ms
Maximum Turn On Time 10ms
Minimum Load Current 150mA
Depth 58.4mm
Height 22.9mm
Input Current 15mA
Isolation Voltage 4000Vac
