Help CenterPower Range 20-500KW Natural Gas Generator CE Cetifiecate Water-cooled With CUMMINS Brand
Related Products
-
Gas Generator 10-1000kw CE Approved by Chinese ManufactureNegotiableMOQ: 1 Set -
ce Certificate 50kw Natural Gas Generator With Factory PriceUS$ 13,900 - 16,000MOQ: 1 Set
-
50kw Natural Gas Generator With Factory PriceUS$ 8,700 - 30,000MOQ: 1 Set
-
ce Certificate 50kw Biogas Generator Price With CHP in Low NoiseNegotiableMOQ: 1 Set
-
ce Certificate 60kva Biogas Generator Price With CHP in Low NoiseNegotiableMOQ: 1 Set
Specifications of 20-500KW gas generator
Gas Genset Introduction
Supermaly series gas generator sets are packaged with famous brand gas engine,alternator and control system.
It features advanced process,rational structure,reliable performance,low noise and vibration,easy to start as well as convenient in installation and maintenance.They are applicable for coil production,various pump stations ,small power station and so on.
Supermaly series gas ganerator set will provide you the best quality and wide-range service.
Gas Genset Features:
Environment friendly:
Natural gas genset with lower exhaust injurant,which is almost not harm for air.
Safe reliabilitt of the genset:
Natural gas genset configurated by brushless self excited alternator with AVR.
Protections perfectly:
Control panel atopts high-quality monitor metres with protections on over-current and less voltage pressure.At the same time,it monitors parameters such as speed,coolant temperature and oil pressure.It alarms and emergency stop when abnormal situation appears.
Running in various ways:
The natural gas genset runs both by single and synchronized.It can also be auto controlled according to customer's requirments.
Running life is long:
It will serve almost 15 years,if it usually runs in a correct way and maintained timely.
Low operation cost and serves extensively:
It can be used as prime power or urgently emergency power in areas in rich of oil or gas .
Cummins brand of natural gas gensets main technical specifications
| Genset Model | Rated Power KW/KVA | Standby Power KW/kva | Engine Model | Cylinder No. | Bore x Stroke(mm) | Gas Consumption(m3/kw.h) | Lube Oil Consumption(g/kw.h) | Alternator Model | Dimention(L*W*H mm) | Net Weight(kg) |
| 20GFT | 20/25 | 22/27.5 | HG4B | 4.L | 102x120 | 0.3 | 2 | PI144E | 1800x710x1350 | 860 |
| 30GFT | 30/37.5 | 33/41 | HG4B | 4.L | 102X120 | 0.3 | 2 | PI144J | 1800x710x1350 | 900 |
| 50GFT | 50/62.5 | 55/69 | HG6B | 6.L | 102x120 | 0.3 | 2 | UCI224E | 2300x820x1400 | 1250 |
| 80GFT | 80/100 | 88/110 | HGN14 | 6.L | 140x152 | 0.3 | 2 | UCI274C | 3150x1000x1500 | 2550 |
| 100GFT | 100/125 | 110/137.5 | HGN14 | 6.L | 140x152 | 0.3 | 2 | UCI274D | 3150x1000x1500 | 2600 |
| 120GFT | 120/150 | 132/165 | HGN14 | 6.L | 140x152 | 0.3 | 2 | UCI274F | 3150x1000x1500 | 2650 |
| 150GFT | 150/187.5 | 165/206 | HGNT14 | 6.L | 140x152 | 0.3 | 2 | UCI274G | 3150x1000x1500 |
2900 |
| 200GFT | 200/250 | 220/275 | HGNT14 | 6.L | 140x152 | 0.3 | 2 | UCI274K | 3150x1000X1500 | 2960 |
| 250GFT | 250/312.5 | 275/344 | HGK19 | 6.L | 159x159 | 0.3 | 2 | HCI444D | 3470x1230X2300 | 3640 |
| 300GFT | 300/375 | 330/412.5 | HGK19 | 6.L | 159X159 | 0.3 | 2 | HCI444FS | 3470X1230X2300 | 3850 |
| 400GFT | 400/500 | 440/550 | HGK38 | 12.V | 159X159 | 0.3 | 2 | HCI544C | 4250X1700X2185 | 5880 |
| 500GFT | 500/625 | 550/687.5 | HGK38 | 12.V | 159X159 | 0.3 | 2 | HCI544FS | 4250X1700X2185 | 6080 |
Our advantage of 20-500kw gas generator
1. 20-500 kw gas generator with engine brand can be Yangdong, Ricardo, etc.
2. We supply spare parts during the whole service life.
3. We are professional genset manufacturer, not trader
4. Decades’ years of manufacturing and exporting experience
5. Adopt International quality standards, to meet high quality requirement
6. Good reputation for Reliable quality & Reasonable price
7. Strong technical support
8. Advanced production line with skilled workers
After sales promise:
1. Since gen-set reached the agreed destination, its main parts will be guaranteed
within 12 months or 1500 hours.
2. We give technical guide all the service life. In the warranty days, we send spare
parts for free. After warranty, we take the spare parts cost.
3. Daily consumed components, wrong operating, lack of maintenance are not include
in the quality guarantee.
