Power Range 20-500KW Natural Gas Generator CE Cetifiecate Water-cooled With CUMMINS Brand

Power Range 20-500KW Natural Gas Generator CE Cetifiecate Water-cooled With CUMMINS Brand photo-1
Power Range 20-500KW Natural Gas Generator CE Cetifiecate Water-cooled With CUMMINS Brand photo-2
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Supermaly
Model Number:
20GFT-500GFT
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shandong, China
Brand Name Supermaly
Model Number 20GFT-500GFT
Output Type AC Three Phase
Speed 1500/1800
Frequency 50/60HZ
Rated Power 20-500KW
Rated Voltage 220V/380V, 230V/400V, 240V/415V
Rated Current 36A-900A



Product Description





Specifications of   20-500KW gas generator





 Gas  Genset  Introduction

    Supermaly series gas  generator sets are packaged with famous  brand gas  engine,alternator and  control system.

      It features advanced process,rational structure,reliable performance,low noise and vibration,easy to start as well as            convenient in installation and  maintenance.They are applicable for coil production,various pump stations ,small power      station and so on.

            Supermaly  series gas ganerator set will provide you the best quality and wide-range service.



 Gas  Genset  Features:

 Environment  friendly:

 Natural gas genset with lower exhaust injurant,which is almost not  harm for air.

 Safe reliabilitt of  the genset:

  Natural gas genset  configurated by brushless self excited  alternator with AVR.

 Protections  perfectly:

  Control panel atopts high-quality monitor metres with protections on over-current and less voltage pressure.At the same time,it monitors parameters such as  speed,coolant temperature and oil pressure.It alarms and  emergency stop when abnormal situation appears.

 Running in various ways:

   The natural gas genset runs both by single and synchronized.It can also be auto controlled according to customer's requirments.

   Running  life is long:

   It will serve almost 15 years,if it usually runs in a correct  way and maintained timely.

   Low operation cost and serves extensively:

   It can be used as  prime power or urgently emergency power in areas in rich of oil or gas .





 Cummins brand of  natural gas gensets main technical specifications





Genset Model Rated Power KW/KVA Standby Power KW/kva Engine Model  Cylinder No. Bore x Stroke(mm) Gas Consumption(m3/kw.h) Lube Oil Consumption(g/kw.h) Alternator Model  Dimention(L*W*H mm) Net Weight(kg)
20GFT 20/25 22/27.5 HG4B 4.L 102x120 0.3 2 PI144E 1800x710x1350 860
30GFT 30/37.5 33/41 HG4B 4.L 102X120 0.3 2 PI144J 1800x710x1350 900
50GFT 50/62.5 55/69 HG6B 6.L 102x120 0.3 2 UCI224E 2300x820x1400 1250
80GFT 80/100 88/110 HGN14 6.L 140x152 0.3 2 UCI274C 3150x1000x1500 2550
100GFT 100/125 110/137.5 HGN14 6.L 140x152 0.3 2 UCI274D 3150x1000x1500 2600
120GFT 120/150 132/165 HGN14 6.L 140x152 0.3 2 UCI274F 3150x1000x1500 2650
150GFT 150/187.5 165/206 HGNT14 6.L 140x152 0.3 2 UCI274G

3150x1000x1500

2900
200GFT 200/250 220/275 HGNT14 6.L 140x152 0.3 2 UCI274K 3150x1000X1500 2960
250GFT 250/312.5 275/344 HGK19 6.L 159x159 0.3 2 HCI444D 3470x1230X2300 3640
300GFT 300/375 330/412.5 HGK19 6.L 159X159 0.3 2 HCI444FS 3470X1230X2300 3850
400GFT 400/500 440/550 HGK38 12.V 159X159 0.3 2 HCI544C 4250X1700X2185 5880
500GFT 500/625 550/687.5 HGK38 12.V 159X159 0.3 2 HCI544FS 4250X1700X2185 6080







Power range 20-500KW natural gas generator CE cetifiecate water-cooled with CUMMINS Brand







OEM CERTIFICATE





Power range 20-500KW natural gas generator CE cetifiecate water-cooled with CUMMINS Brand



MAKING MACHINE

 Power range 20-500KW natural gas generator CE cetifiecate water-cooled with CUMMINS Brand





Our advantage of    20-500kw gas generator



1. 20-500 kw  gas generator with engine brand can be Yangdong, Ricardo, etc.

2. We supply spare parts during the whole service life.

3. We are professional genset manufacturer, not trader

4. Decades’ years of manufacturing and exporting experience

5. Adopt International quality standards, to meet high quality requirement

6. Good reputation for Reliable quality & Reasonable price

7. Strong technical support

8. Advanced production line with skilled workers





Our Services



After sales promise:



1. Since gen-set reached the agreed destination, its main parts will be guaranteed

within 12 months or 1500 hours

2. We give technical guide all the service life. In the warranty days, we send spare

parts for free. After warranty, we take the spare parts cost.

3. Daily consumed components, wrong operating, lack of maintenance are not include

in the quality guarantee.

Power range 20-500KW natural gas generator CE cetifiecate water-cooled with CUMMINS Brand





     If u have any questions,please email or add me on skype:bngd607.





Power range 20-500KW natural gas generator CE cetifiecate water-cooled with CUMMINS Brand
