Konics KR-100N Intelligent Hybrid Recorder Korea Recorder

Specifications

Konics KR-100N Intelligent hybrid recorder Korea recorder
authorized Autonics Konics distributor
KR-100N provides up to 12 channels of input measurement range
with high accuracy and individual control.
* Easy operation
* Clear printing
* Multi input per channel (TC, RTD, mV, V, mA)
* 12 channel input in 100mm
* 6 point alarm relay output
* RS485 communication
* Diverse filter selection
* CE
* Recording type :1, 2, 3 Channel Type/6, 12 Dot Type
* Input : Multi (T/C, RTD, V, mV mA)
* Measuring interval : 1sec(1,2,3ch), 6sec(6,12Dot)
* Accuracy : Indicating : ±0.25% F?S
            Recording : ±0.5% F ? S
* Recording method : Recording by 6 color pen
* Interval : Over 3sec
* Recording Speed : 10, 20, 40, 60, 120, 240mm/h
* Recording Paper : Konics Kr-100N exclusive 9M
* Power supply : 85-264VAC, 47~63Hz
* Size (mm): 144(W)×144(H)×235(D)
* Alarm: 6 point alarm relay output
* Communication output : RS485
