Specifications
Konics Power supply unit DPU3D-R Digipower 2000 Thyristor Regulator Korea Digital Power Thyristor Unitauthorized Konics
Konics Power supply unit DPU3D-R Digipower 2000 Thyristor Regulator Korea Digital Power Thyristor Unit
authorized Konics distributor
This unit as instrument controlling power by semiconductor element
having control function of current or voltage,
consist of single phase and 3-phase
there are “Static voltage type”, “Static current type”, and “Static power type” output
not changed regardless of the changes of input value.
It is available for select the type in accordance with heater type,
application and the load capacity as well as circuit protection function
by means of compact design is excellent also operation method is easy.
Konics’newly developed digital power controller DPU series
real all-in-one power controlling total solution
satisfying with all your requirements in the industrial field.
It guarantees highly precise & full RMS power control,
quick response and better reliability.
* Precise feedback (static current, static voltage, static power) by measuring RMS value
* Adoption of phase control and zero-crossing cycle control (fixed cycle, variable cycle) for various load
* Fast responding time by high-speed CPU
* Including customized 6 digital inputs (Event input)
* Various alarm output including current error, heater disconnection, etc.
* Indicating various setup, input/output by 7 segment and bar LED
* MODBUS RTU protocol by RS485 communication
* Control input signal : current, voltage, potentionmeter, etc.
* Available for installation by remote control panel
* Control method : Feedback control mode – static voltage, static current, static power control
Normal mode – Phase angle control, Zero crossing fixed (or variable) cycle control
* Capacity of current : 25~600A, 750A (Upon request)
* Control power supply : 110, 220, 380, 440VAC ±10%, 50/60Hz
* Circuit power supply : 80~240VAC, 50/60Hz(Extra supply not necessary),7W(MAX)
* Output control range : 0~98%(Phase angle control), 0~100%(Zero crossing control)
* Control input : -Auto : 4~20mA, 1~5V, 0~10V
-Man : VR
Send Inquiry to This Supplier
