Jet Self-priming Pump for Domestic and Industrial

Jet Self-priming Pump for Domestic and Industrial thumbnail-1
Jet Self-priming Pump for Domestic and Industrial photo-1
US$ 25 - 35 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Twain
Model Number:
JET
Contact Supplier Request Quote Chat Now
Fujian Tianyi Motor Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name Twain
Model Number JET
Theory Jet Pump
Structure Single-stage Pump
Usage Other, Water, For Garden pumping
Power Electric
Standard or Nonstandard Standard
Fuel Other, Electric
Pressure High Pressure
Application Other, Pumping Water

Specifications

Jet Self-priming pump for domestic and industrial
1.Fast Delivery
2.CE,ISO
3.Competitive Prices
4.One Year Warranty

Jet Self-priming pump for domestic and industrial

1.Product Overview



INTRODUCTION:

The JET series are suitable for pumping clean water. They are particularly suitable for domestic applications such as supply water from well, pool etc, the automatic distribution of water by surge tanks and pressure switch, gardening, and increasing of water pressure.



APPLICATION:

1.JET-100 pump,Water pump,Self-priming JET Pump Self-priming jet water pumps with a very high hydraulic performance and a considerable pressure capacity.
2.Able to pump up to 9mt.depth and work perfectly even in soda-water.
3.Suitable for water lifting and distribution in domesticfittings by small and medium sized tanks.





FEATURES:

1.JETL Series pump is constituted with clean water pump, non-return valve and air-water separation room, which located on the upside of the pump body.

2.During operating, it is no need to use foot valve, the only thing that you should do is just leave some water in the pump body.

3.After a few minutes' running, the water will be sucked out relying on the pump body itself.

4.They are particularly suitable for domestic applications such as supplying water from well, pool etc.

5. It is also suitable for water pressure boosting, gardening and automatic water supplying if combined with other appliances.



CONSTRUCTION:

Pump body: Cast iron

Impeller: Brass

Motor Housing: Aluminium
Front cover: Cast iron
Mechanical seal: Ceramic - Graphite

Shaft: steel or stainless iron
Bearing: SKF/NTN/NSK/China
Insulation class: B and F
Protection class: IP44



OPERATION CONDITIONS:

Max Temperature of Fluid to +80C

Max Pressure 10bar

Max Ambient Tenperature up to 40C



TECHNICAL DATA:

Model Power Q.max. H.max. Suct.max. Speed Pump dia. PACKAGE DIMENSIONS & GW
HP KW L/min m m r.p.m Inlet/Outlet A B H Kg
JET-60L   0.6 0.45 40 35 9 2850 1"*1" 205 480 230 14.5
JET-80L   0.8 0.6 50 40 1"*1" 210 490 230 16.5
JET100L 1 0.75 60 45 1"*1" 210 490 230 17.5

 Jet Self-priming pump for domestic and industrialJet Self-priming pump for domestic and industrialJet Self-priming pump for domestic and industrialJet Self-priming pump for domestic and industrial
