Specifications
1) SD LD series single cylinder diesel engine2)water-cooled, four-stroke
3)Combustion: Swirl chamber, DC chamber
Specification of SD LD Series Single Cylinder Diesel Engine (2kW-25kW):
1) Models: SD/LD195, SD/LD1100, SD/LD1100A, SD/LD1105, SD/LD1110,
SD/LD1115, KM130, KM138, KM160
2) Type: Single-cylinder, horizontal, water-cooled, four-stroke
3) Combustion: Swirl chamber, DC chamber
4) Bore x stroke (mm x mm): 95 x 115, 100 x 115, 105 x 115, 110 x 115,
115 x 115, 118 x 118, 122 x 118, 125 x 120
5) Total piston displacement (L): 0.815, 0.903, 0.996, 1.093, 1.194, 1.29, 1.38,
1.473
6) Compression ratio: 17-18, 16-18, 17, 16-18
7) Maximum Power / Speed (HP/rpm): 12/2000, 15/2200, 18/2200, 20/2200,
22/2200, 24/2200, 27/2200, 30/2200
8) Fuel consumption (g/kW.h): 258.4, 257, 252, 252, 252, 252, 252, 252
9) Cooling: Circulating pumps mandatory, evaporation and dual-circulation
pumps mandatory
10) Lubrication: spatter compound with pressure
11) Starting way: rattle starter, electric starter
12) Quality Net (kg): 160, 165, 180, 190
13) We can also supply CKD for diesel engines
Packing:
wooden case
