The specification of Cummins dieesel generator:
Genset Model |
SC80GF |
|
Prime Power (kw/kva) |
80kw/100kva |
|
Standby Power (kw/kva) |
80kw/100kva |
|
Diesel Engine |
Model |
6BT5.9-G2 |
Type |
open/close |
|
Rated Power(kw/kva) |
80kw |
|
Intake Type |
Turbocharged |
|
No. of Cylinder |
6.L |
|
Bore*Stroke(mm) |
102*120 |
|
Compression Ratio |
16.8:1 |
|
Displacement (L) |
3.9L |
|
Noise Level(dBA) |
≤96 |
|
Exhaust Temperature |
510℃ |
|
Alternator |
Model |
XN274C |
Rated Power |
80kw |
|
Excitation Type |
Brushless |
|
Note: MARATHON ,LEROY SOMER and other brand of alternator is avaliable as your requirement.
Packed with wrapped film as standard,plywooden case for options
When we finished the test of diesel generator,our transporation department then will take charge
of sending the generator to the container at port of loading,with help of our excellent forwarder,
we send our generators to our customers successfully without any damage.
Warranty policy
Guarantee for one year or 1500 hours whichever reach first from ex-factory date.
During the guarantee period, we will provide the free easy-damageable spare parts of diesel engine caused by our quality of production or raw material.
After expiration, we provides cost spare parts maintenance of gensets
OEM Service
We can provide professional OEM Service for customers.
1. Unique design and manufacture of generator according to customers requirement.
2. Customer logo printing or painting on the genset.
3. Installation and Operation manual neutral or headings can be design according to
customer requirement.
4. Full warranty cover to support customers.
Shandong Supermaly Generating Equipment Co., Ltd. is located in Weifang City, knowned as "Power City of China", Shandong Province. We are a high technology enterprise of Shandong Province, primarily engaged in land using and marine diesel generating sets, pump sets, and diesel engines.
The power range of our generating set is from 8KW to 1000KW. It is coupled by world famous brand engines such as PERKINS, CUMMINS, DEUTZ, STEYR and RICARDO etc., with world famous brand alternators such as STAMFORD, MARATHON and LEROY SOMER, etc. We also can supply most generating sets coupled by Chinese brand engine and alternator. Besides, we are an OEM factory of Perkins engines and Stamford alternators.
We have participated in many kinds of exhibitions all over the word,like Canton Fair,Russia Power,Turkey exhibition etc.
Our products are with certification of ISO9001:2000,CE,SONCAP and other international
authoritative institutions and the quality system certification.
FAQ(Frequently Asked Question):
1. What is your warranty period?
Our payment terms is 1 year or 1500 running hours whichever comes first. But based on some special project, we can extended our warranty period.
2. Does your generator have global warranty?
Yes, most of our products like Perkins, Doosan, Yuchai, Deutz, Volvo power generator enjoy the global warranty service. And the alternator we use like Leroysomer, Stamford, marathon also enjoy the global warranty service, so you do not need to worry about the aftersales service.
3. Can you accept OEM?
Yes, we can accept OEM.
4. What is your payment terms?
We can accept T/T 30% in advance, and the balance 70% shall be paid before shipment or L/C at sight, L/C deferred payment terms or west union.
5. What is your delivery time?
Our normal delivery time is 15-20 days. But if your order is some special engine and alternator, then the delivery time is longer.
Supermaly main products:
Diesel generator set: power by Perkins, Cummins, Doosan,Deutz, Volvo, Yuchai and son on.
Natural gas generator set: power by Perkins, revised Cummins, Yuchai.
Generator type: open generator, silent generator, mobile generator.
