Specifications
Prime UPN 100-300 ,effect shipment immediately, promise the quality and quantity .U channel
1.Grade: SS400/Q235/ST37-2/A36/S235JR
2.Size: 50*25-200*90
3.Length :5.8/6/9/12m
Dimensions (mm) |
Web thickness (mm) |
Flange thickness (mm) |
Weight (kg/m) |
50*25 |
3.0-5.0 |
5.0-6.0 |
2.370-3.460 |
75*40 |
3.8 |
7.0 |
5.300 |
75*40 |
4.0 |
7.0 |
5.600 |
75*40 |
4.5 |
7.0 |
5.850 |
75*40 |
5.0 |
7.0 |
6.920 |
100*50 |
3.8 |
6.0 |
7.300 |
100*50 |
4.2 |
6.0 |
8.030 |
100*50 |
4.5 |
7.5 |
8.970 |
100*50 |
5.0 |
7.5 |
9.360 |
125*65 |
5.2 |
6.8 |
11.660 |
125*65 |
5.3 |
6.8 |
12.170 |
125*65 |
5.5 |
8.0 |
12.910 |
125*65 |
6.0 |
8.0 |
13.400 |
150*75 |
5.5 |
7.3 |
14.660 |
150*75 |
5.7 |
10.0 |
16.710 |
150*75 |
6.0 |
10.0 |
17.900 |
150*75 |
6.5 |
10.0 |
18.600 |
150*75 |
9.0 |
12.5 |
24.000 |
200*80 |
7.5 |
11.0 |
24.600 |
200*90 |
8.0 |
13.5 |
30.300 |
