diesel engine powered diesel generator set with stamford alternator
Diesel Generator Set:
The engines of Engines brand being produced and sold by Engines are classical engines with European origin and modern leading technology, aiming at the demands of global engine field. engines are high-tech engine products with powerful dynamic force, environmental protection, fuel-saving and fine manufacture, which come down in one continuous line of European technology. Currently, main products of the company include two series of Feichi and1000, more than 80 varieties, more than 200 kinds of products, power range of the products is in 42~170KW, speed range is 1500~2800rpm, these products can be used as a dynamic force of the equipments, such as trucks, passenger cars, agricultural machines, construction machinery, loading/unloading machinery, generating sets, and so on.
Technical Data:
GENSET MODEL |
PRIME POWER |
STANDBY POWER |
ENGINE MODEL |
DIMENSION (LXWXH) mm |
WEIGHT (kg) |
||
KVA |
KW |
KVA |
KW |
||||
GFL30 |
28 |
22 |
30 |
24 |
1003G |
2150X750X1340 |
800 |
GFL50 |
45 |
36 |
50 |
40 |
1003TG |
2150X750X1340 |
820 |
GFL65 |
60 |
48 |
65 |
52 |
1004TG |
2350X750X1400 |
870 |
GFL78 |
70 |
56 |
77.5 |
62 |
1004TG |
2350X750X1400 |
920 |
GFL100 |
90 |
72 |
100 |
80 |
1006TG1A |
2500X750X1500 |
1180 |
GFL110 |
100 |
80 |
110 |
88 |
1006TG2A |
2500X750X1500 |
1180 |
GFL125 |
112.5 |
90 |
125 |
100 |
1006TAG |
2700X900X1500 |
1300 |
GFL150 |
135 |
108 |
150 |
120 |
1006TAG |
2700X900X1500 |
1400 |
Diesel Engine Volvo:
1. Diesel engine:Lovol engine
2. Naturally aspirated, turbocharged, water cooled or turbocharged with air intercooler
3. Machinery or electronic governing
4. Fuel injection pump
5. Electric motor starting system
6. Forged steel crankshaft, cast iron cylinder and replaceable wet type cylinder liner
7. Low discharge, and low fuel consumption
Alternator Features:
1. World famous brand AC alternator: Leroy Somer, Stamford, Marathon, ENGGA
2. Brushless, 4 poles, rotation magnet
3. IP21-23(NEMA1) enclose is standard for all industrial alternators
4. H class insulation system
5. AVR self-regulated, voltage regulation rate: ±1%
6. Simple installation and maintenance with easy access to terminals, rotating diodes and coupling bolts
7. Wide range of flange adaptors and single bearing disc coupling
8. Radio interference restraining accords with the stipulation of VDE0875-N and ISO8528
9. Moisture proof, sand-proof, dustproof, salt-proof and vibration-proof
Control system:
1 a) Automatic alarm system: the unit has the acousto-optics alarm system and arrestor for any situation as the start defeat, the water is over temperature, the oil pulls down, over speed, over load and over current
b) Operation display:
i) Unit voltage, tri-phase load current and frequency display
ii) Water temperature, oil pressure display
iii) Fuel level, fuel temperature display
iv) Audible and visual alarm lamps and buzzers
2 Starting system: DC alternator is used to start engine
3 Short circuit protection: MCCB air switch
4 Cooling system: combined cooling water tank fitted to meet the requirement of radiation at ambient temperature 40°C
5 Filter system: oil, fuel and air filter
6 Accessories: exhaust elbow, bellow, muffler
PMC System:
1. Standard 23 pitch windings avoid excessive neutral current
2. Permanent magnet generator system provides constant excitation under all condition
3. Optional accessories available for easy paralleling with mains or other generators
4. AVR auto voltage regulation, auto exciter, auto adjustment
Soundproof/Silent Box:
1. Excellent ventilation
2. Oil tank mounted on base frame for 12 Hours working
3. Highly Corrosion Resistant construction
4. Excellent Access for Maintenance
5. Security and Safety
6. 1m<80 dB / 7m<70dB
Accessories:
1) Standard accessories: Common steel frame, circuit breaker, damper, exhaust silencer, flexible pipe, battery and connecting wires, operation manual and document
2) Optional accessories: Engine coolant and oil heater, alternator space heater, cooling for heat exchanger, control system with RS232/485, communication interface, battery charger by main supply, daily fuel tank, ATS and paralleling system, soundproof canopy and moving trailer
