Product introduction:
The X3G860 is a reliable and rugged analyzer that maximizes both speed and accuracy. The need to determine whether an ID is incorrect or if longer testing is required needs to be balanced with maximum testing speed without increasing the risk of mistaken IDs or erroneous readings. X3G’ Smart Real solution automates all these decisions, enabling even inexperienced operators to maximize both speed and inspection accuracy. This powerful feature yields optimized throughput and accuracy, making the X3G an extremely productive XRF tool for all precious metal inspection.
Suitable quality and technology supervision department finds that the quality control shop, as well as the People's Bank acquired gold processing sector. NDT, easy to operate.
Full-featured automatic management software, gold, platinum, platinum K platinum jewelry in gold, silver, copper, palladium, nickel, zinc, indium, iridium do quantitative analysis with high accuracy, in line with GB / T 18043-2000 required for platinum accuracy palladium, nickel content analysis, serial port communication, non-destructive measurement, test time between a few seconds, platinum and silver jewelry for copper and nickel analysis error is less than 0.3 to 0.5%. Of error is less than 1% of platinum, platinum, K white gold, platinum, palladium, nickel, copper do quantitative analysis of gold, silver, nickel plating thickness do sample analysis (less than 5 microns) suitable for electroplating industry product quality control, quality and technology supervision department finds that the quality control shop, gold production and acquisitions.
The X3G Knows Metal and Alloys
When you need a reliable analysis tool to provide fast and accurate Positive Material Identification, turn to the X3G. From turnings, shavings, rods, and wires to small parts and components, to more sizeable material or structures, the X3G provides anywhere, anytime testing with faster and more accurate results than ever before.
Specifications
Model: X3G860
Weight: 1.5 kg with batteries
Dimensions: 30cm(L)*23.5cm(W)*9.8cm(H)
Excitation Source: X-ray tube with Ag target; max voltage 50KV
Filters Five (5) available automatic filter positions
Detector: Peltier cooled 10 mm2 Silicon Drift Detector
Power: 2 rechargeable Li-Ion batteries; 6 hours operation per battery; AC adapter is optional
Operating Range: -10°C to 50°C
Computer/Display: with 65,536 colors; back lit; touch screen
Testing Modes Assay and Pass/Fail
Calibrations
Universal (automatically selects proper calibration); Polyethylene plastics; PVC
plastics; Mid-density (glass, ceramics); Alloys; Solders
Data Storage: 16GB standard memory.
Radiation Safety Password protected, No sample (backscatter) shutoff, five minute inactive log-in
Languages Supported: English, Chinese and other 5 languages
Warranty: One year
