X3G600 Handheld RoHs Spectrometer: RoHs & WEEE Analysis

X3G600 Handheld RoHs Spectrometer: RoHs & WEEE Analysis thumbnail-1
X3G600 Handheld RoHs Spectrometer: RoHs & WEEE Analysis photo-1
US$ 20,000 - 30,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shaanxi, China
Brand Name:
zealchon
Model Number:
600
Contact Supplier Request Quote Chat Now
Xian Zealchon Electronic Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shaanxi, China
Brand Name zealchon
Model Number 600
Power Electronic
Usage Other, Handheld RoHs Spectrometer



Product Description



X3G600 Handheld RoHs Spectrometer Technical Parameters





Weight: <1.6kg







Dimensions: 300mm*235mm*98mm







Excitation Source: high performance mini X-ray tube and power(50KV/200uA maximum)
X-ray Detector: High performance Si-Pin/SDD detector, Peltier cooling, resolution<160eV







Circuit system: DSP embedded system
Battery: 2 rechargeable lithium batteries with heat exchanging,110V/210V common charger,use 4~6h continuously,the charging time is about 2h.
Display: Fixed angle integrated colorful backlight LCD touch screen



Detection time: 10-200s (handheld or stand type test)
Detection limit: All elements from S~U (can change as per to application)
Element detection limit: 10ppm~100ppm




X3G600 Handheld RoHs Spectrometer Main Features:







Super large power: 50KV,200uA,4W X-ray tube lets equipment have lower detection limit.
EM interference is banned,then even it close to mobile phone or double way wireless communication devices also can work normally.
Can endure severe working condition.Full metal high intensity case is more conductive to thermal dissipation,then it can work under 35℃ super low temperature with excellent resolution,so it can normally operate in rainy and dusty mine environment.
Amazing test precision: just 30s to improve composition accuracy in sample to common instrument level.
Professional software for geological mineral sample element test,it has features of high sensitivity,short test time,simple operation and few limit to operator.
Small power integrated mini tube,high excitating efficiency,combining with large area berylium window cooling Si-Pin detector,so it owns the similar geological mineral sample test function with desktop instrument.







X3G 600 Handheld RoHs Spectrometer can analyze the following fast:







Cd,Pb,Br,Hg,Cr element content in electronic components,adapting units and printed wiring board etc.
Raw material status and Sn,Pb,Cu,Ag,Bi content containing in various solders.
Cd,Pb,Br,Hg and Cr content in plastic and ceramics.
Element composition of metal and fasteners and material code analysis.
Whether there is enough lead in highly reliable system.
Cd,Pb and Hg content in package materials
PVC,Br or Sb content in plastic products to accomplish recycle and sorting.









Packaging & Shipping

 X3G600 Handheld RoHs Spectrometer: RoHs & WEEE Analysis







Our Services



The warranty  is one year, within 1 year, if  there is any  problems, we will follow you to slove it, and could do the

replacement for the parts and accessoires.



if still does not working after checking, the machine could be send back.



Anyway, we will try our best to make sure your after-service is totally fufilled if there is any concern
