B060 Stable Inorganic Binder Material Fatigue Testing Machine
US$ 3,000 - 5,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shaanxi, China
Brand Name:
zealchon
Model Number:
b057
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
A121 Lab Pavement Compression Fatigue Test SystemUS$ 10,000 - 90,000MOQ: 1 Piece -
B002 Continuous Eight Wheels Profilometer/Pavement ProfilometerUS$ 3,600 - 3,700MOQ: 1 Set
-
B003 Portable Pavement ProfilometerUS$ 1,200 - 1,300MOQ: 1 Set
-
A104 Ultrasonic Coating Thickness GaugeUS$ 5000.00 - 5000.00MOQ: 1 Set
-
A104 Digital Ultrasonic Coating Thickness GaugeUS$ 5,000 - 6,000MOQ: 1 Set
Place of Origin
Shaanxi, China
Brand Name
zealchon
Model Number
b057
Power
Electronic
Usage
Other, fatigue testing machine
Product Description
It adopts the tests such as four-point bending, uniaxial compression, Creep springback etc. Under the specified test conditions, it can measure thefatigue life of compaction inorganic binder under repeated load. System supports a variety of test types such as damaged max force, Creep springback, The fatigue stress etc.
| Technical Parameters | |
| Parameter Names | Details |
| Loading system parameters | |
| Size | length 1250mm×width900mm×height3000mm |
| Servo actuator | 210mm |
| distance of Beam moving up and down | 1000mm |
| Oil cylinder, bar up and down rate | 0.1mm/min~100mm/min |
| Servo actuator maximum output | 200kN |
| displacement | 0~5mm or0~10mm |
| distinguishability | 2μm |
| Accuracy | ±5μm |
| swing | 0.2mm~5mm optional |
| Technical parameters of the servo oil source control system | |
| Size | 1300×1200×1750mm |
| rated working pressure | 21MPa |
| Maximum output flow pump sources | ≥100L/min |
| return pressure | ≤0.5MPa |
| power supply | 380V 50Hz |
| motor power | 37kW |
| Temperature control environment box technology parameters | |
| Size | 1900mm×800mm×2100mm |
| Compressor power | 1.5P |
| Heating power | 400W |
| Internal sizeof environment box | 440×460×830mm |
| Temperature control range | ~20°C~60°C |
| Power supply | 220V 50Hz |
Product picutres:
