New model bus 6m14-19 seats diesel china mini bus
- 200 Unit / Units per Month
- Shanghai
- T/T
- Toyota Coaster bus seat
- Toyota Coaster bus seat,kinglong bus seat, golden dragon bus seat,coaster bus seat
- Philippines Centro ISUZU MITSUBISHI TATA FUSO HINA SUZUKI FOTON Modern PUV electric folding bus door opener (BDM100-N)
- Philippines E-jeepney/electrical jeepney electric folding bus door opener (BDM100-N)
- Philippines PUV vehicles electric folding bus door opener (BDM100-N)
- Automobile electrical folding bus door pump
Product Details
Seats: | 11 - 20 | Emission Standard: | Euro 4 | Transmission Type: | Manual |
Max Speed: | 91 - 110 km/h | Steering Position: | LHD | Fuel Type: | Diesel |
Dimensions (L x W x H) (mm): | 5995*2265*2750/2950 | Place of Origin: | Jiangsu, China | Brand Name: | HUAXIN |
Model Number: | HM6602LFD4X |
Product Description
Name: China supplier new design 6m14-19 seats diesel mini city bus sales
Specifications | |||
Model | HM6602LFD4X | ||
DIMENSIONS & WEIGHTS | |||
Overall dimension (mm) | Length | 5995 | |
Width | 2265 | ||
Height | 2750,2950 | ||
Wheelbase (mm) | 3300 | ||
Thread (mm) | Front/rear | 1750/1586 | |
Curb vehicle weight (kg) | 3970,4100 | ||
Gross vehicle weight (kg) | 5450,5580 | ||
Seating capacity (persons) | 14-19 | ||
ENGINE | |||
Model | YC4FA115-40 | ||
Type | 4-cylinder, in line, water-cooled, direct injection, diesel, turbocharged Inter-cooling | ||
Displacement (cc) | 2982 | ||
Max. Power (hp/rpm) | 85/3200 | ||
Max. Torque (N-m/rpm) | 300/1600-2400 | ||
Fuel tank (liter) | 70 | ||
DRIVE TRAIN | |||
Clutch | Hydraulic, Single plate, dry type diaphragm spring | ||
Gearbox | 5 speed manual | ||
Max. gradeability (%) | 30 | ||
CHASSIS | |||
Frame | Ladder shaped, ‘] ’ section | ||
Suspension, front/rear | Leaf springs | ||
Shock absorber, front/rear | Double action shock absorbers | ||
Steering | Recirculating-ball | ||
Brake | Type | Air brake | |
Front/rear | Drums | ||
Power steering | With | ||
Min. turning radius (m) | 7.5 | ||
Tires | 7.00-16,7.00R16 | ||
|
