Various Colors 4 Digit Indoor 7 Segment Led Display

various colors 4 digit indoor 7 segment led display

Features:

1.Low power consumption

2. long life according to experiments

3. High efficiency

4. Industrial standard size

5. Luminous evenly distributed on each segment

6. Provides excellent reliability in bright ambient light

7. Sold state reliability

8. Competitive price

9. Size and colors can be provided by your application

10. Chips sourced from Taiwan and America

11. Imported PCB

12.Fire proof REF

13.Fits different LED displays size specifications

14.ISO9001-2008 and ROHS certificate

Forward Voltage;

Red: 1.8v to 2.5V

High bright red/orange: 2.0V

Blue/pure green: 3.5v

Green:2.2v to 5.0v

yellow/amber: 2.0v to 5.0v

Dominant Wavelength and Luminous Intensity:

Red: 620nm to 650nm, 50mcd to 60mcd

High bright red: 620nm to 625nm, 80mcd

Green: 560nm to 570nm, 13mcd to 14mcd

Pure green: 505nm to 530 nm, 180mcd

Yellow: 585nm to 595 nm, 14mcd to 50mcd

Orange: 600nm to 610nm, 30mcd

Applications:

1.Audio equipment or Instrument panels

2.General use for digital indicators

3.Multimedia product

4.Digital read out display

Attention: Lead Soldering Temperature: 260°C for 3 seconds. For operation above 25°C, The Ifm Ifp & Pd must be derating , the Current derating is –0.36mA/°Cfor DC drive and -0.86mA/°Cfor Pulse drive, the power dissipation is -0.75mW/°C. The product working current must not more than the 60% of the Ifm or Ifp according to the working temperature

Related products:

Our quality certificates:

About us:]

Aite Aiko Technology(shenzhen) Co. Ltd.

We are ISO certificate manufacture and we specialized in 7 segment LED display of various sizes and colors, custom LED display and LED dot matrix, these are widely applied for electric appliances. Our products are selling well for their high quality and favorable prices. Our destination is “ To pursuit excellence on the basis of good faith”, therefore provide better products and services to our customers. Just give us a chance!
