2 digit 14 segment alphanumeric display
Our extremely bright, outdoor and indoor digital Data-Displays became very popular due to their simplicity of use, nice sleek design and very powerful broadcasting ability. Use it as a communication tool with potential shoppers passing by your business and you’ll be surprised by the impact on the audience they’re making. This affordable solution is a must for every business to search for new clients and for those who are looking forward to reinforce their brand image.
Every single display can be linked to any auxiliary equipment to gather and display live data. It can also be linked to the secured wireless network so you can control it from anywhere within network.
Specification
1.Electrical optical charactertistics(Ta25°C)
Parameter |
Symbol |
Min |
Type |
Max |
Unit |
Test Condition |
Luminous Intensity |
IV |
165 |
182 |
185 |
mcd |
IF=20mA |
Peak Wavelength |
λp |
|
|
|
nm |
IF=20mA |
Dominant Wavelength |
λd |
510 |
511 |
512 |
nm |
IF=20mA |
Forward Voltage |
Vf |
3.0 |
3.2 |
3.5 |
V |
IF=20mA |
Reverse Current |
IR |
|
|
50 |
uA |
VR=5V |
Suggestion Forward Current |
IF |
3 |
5-10 |
20 |
mA |
IF=20mA |
2.Absolute Maximum Ratings (Ta=25°C):
Parameter |
Rating |
Unit |
Reverse Voltage |
5 |
V |
Power Dissipation,Per Dice |
50 |
mW/chip |
Operating Temperature Ranger |
-48~+85 |
°C |
Storage Humidity |
45%~85% |
°F |
Storage Temperature Ranger |
-40~+90 |
°C |
Soldering Temperature |
260°C For 3 Seconds |
|
Peak IF(ma) (1/10Duty Cycle 0.1ms Pulse Width) |
100 |
mA/chip |
Continuous Forward Current |
20 |
mA/chip |
Dimension
Alphanumeric display
2,Led dot matrix:
Introduction of our company
SHENZHEN AITEAI TECHNOLOGY CO.,LTD.
Our company is specialized in LED diode, nixie tubes, dot matrix modules, clock plate, back plate, and all kinds of internal and external LED display screen with single or dual color etc.
Our products sells well for uniform brightness and enjoy a great reputation in China . Products derease less than 1% brightness within 1 year. With many years experience in production and management, we can offer customers with reliable quality, favorable price of LED display.
Our belief is "to pursuit excellence on the basis of good faith". Our purpose and dedication is to provide our customers the best quality and service.We have full experience in cooperating with some big companied such as TCL,Desay etc.
One of my hobby is to make friends with my customers. You will get a surprise when you enter into business with me!
we do believe we can become your reliable supplier!
