PV Inverter 3KW Grid-tied

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Sichuan, China

Brand Name:

DHC

Model Number:

DHSP1GC-3KTL

Dongfang Hitachi (CD) Electric Control Equipments Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin/ Shanghai/Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Sichuan, China

Brand Name DHC

Model Number DHSP1GC-3KTL

Key Features and Advantages

Grid-tied PV inverter designed for commercial or residential applications.

More power harvesting with 2-MPPT decentralized tracking technology, advantageous over single MPPT in cloudy weather

conditions.

Overall power efficiency up to 98.7% with advanced algorithm.

Reactive power adjustable, ranging from 0.9 lag to 0.9 lead.

Specially design for outdoor installations (IP65), adaptable to harsh environment. Derating operation between 3000m and

6000m for high altitude applications.

Grid friendly with pure sine wave output, minimal harmonic pollution and impact to the power grid.

Integrated RS485/RS232 and GPRS communication interface for remote monitoring.

Light weight, easy to install, and the whole system can be integrated into one cabinet.

Technical Specifications:

DHSP Series Grid-tied Solar Inverter (3kW)

Model		DHSP1GC-3KTL
DC Input	Max. Input Power(kW)	3.3
	Max. Input Voltage(V)	520
	Max. Input Current(A)	18
	MPPT Range(V)	150~500
AC Output	Nominal Output Power(kW)	3
	Max. Output Power(kW)	3.3
	Rated Output Current(A)	15
	Grid Voltage Range(V±%)	230±10%
	Grid Frequency(Hz)	50/60±0.5
	Max. Efficiency(%)	>97.4
	European Efficiency(%)	>96.3
	Power Factor Range	0.9 (lag) ~ 0.9 (lead)
	Total Harmonic Distortion (%)	≤3% ( Rated. Power)
System	Ingress Protection	IP65 (outdoor)
	Insulation Class	H
	Cooling Method	Air blast
	Display	OLED
	Communication Interface	Ethernet, RS485, GPRS
	Dimension (W×H×D) (mm)	414x560x200
	Weight(Kg)	27
Environment	Operating Temperature (℃)	-35℃ ~ +50℃
	Operating Humidity (%)	<95%, without condensation
	Installation	Indoor, in a dust free environment free of hazardous or flammable material
Protection	Over-current, DC Over-voltage, AC Short-circuit Over/under-voltage of grid, Over/under-frequency of grid Anti-Islanding, Reverse Discharge, Reverse Polarity
