Specifications
1. Brand Changchai diesel generator2. CE, ISO, CCC
3. 100% copper
4. Belt driven
5. double bearing
single cylinder diesel generator changchai engine 20
Specifications
Changchai Diesel Generator In Guangzhou
1)changchai Diesel Generator
2)Open,Silent Type Option
3)Globally Warranty
4)CE, ISO9001-2008, CCC
Changchai diesel generator widely used in the area of industry, agriculture railway and construction.Diesel generators are widely used in schools ,hospitals ,hotels and
other industries with the power of 3kw-20kw.As a standby or temporary
power ,they were applied well. Our company promise to our quality of
small diesel generators sets and the price is favorable. Welcome to our
factory to purchasing the production
We can supply Weichai series generator sets ranging from 3Kw-24Kw
Brand Changchai diesel generator
Specification of genset
Technical Specifications | ||
Diesel Generator Set |
Model No. |
RMG20 |
Rated output(KW/KVA) |
20/25 |
|
Size(mm) |
1450*670*790 |
|
Weight(KG) |
360 |
|
Diesel Engine |
Model No. |
ZS1125 |
Engine characters |
Straight line, watecooling, four stroke,direct injection |
|
Cylinder NO. |
1 |
|
Aspiration |
Natural aspiration |
|
Compression ratio |
17:1 |
|
Displacement(L) |
1.194 |
|
Start type |
manual operation or DC 12V electric start |
|
Rated Speed(rpm) |
1500 |
|
Rated fuel consumption(L/h) |
≤244.8(g/kw.h) |
|
Alternator |
Model No. |
STC-20 |
Excitation type |
Brush/Brushless |
|
Insulation class |
H |
|
Brand |
STC/Stamford/Stamford copy |
|
Voltage(V) |
230/400 |
|
Current(A) |
36A |
|
Frequency(HZ) |
50HZ |
|
Power Factor |
0.8 |
|
Phase |
3 phases, 4 wires |
|
Send Inquiry to This Supplier
