Help CenterManufacturer Offer Stc 20 Kva Generator Price
Related Products
-
Safely Home Used 10kw Stc Generator India PriceUS$ 350 - 420MOQ: 1 Set -
Safely Home Used 20kw Stc Generator India PriceUS$ 350 - 420MOQ: 1 Set
-
Safely Home Used 30kw Stc Generator India PriceUS$ 450 - 480MOQ: 1 Set
-
Safely Home Used 50kw Stc Generator India PriceUS$ 450 - 480MOQ: 1 Set
-
24kva-2000kva Shanghai Diesel Generator Manufacturer in EuropeNegotiableMOQ: 1 Set
Specifications
1 stc 20 kva generator2 safely used
3 factory price
4 CE approved
About stc series generator
stc series generators are to be used in town,the countryside,worksides,moountain and pasture lands as a electric power source for lignting purpose,it can also be used as a reserved power source for emergent case.The generators are of drip-poof with rotary field type and with the adoption of harmonic excitation system,that allow your easy operation and simple maintenance.The generators are of three-phase four-wire type,making use of atar connection with neutral point.The rated line voltage is 400V.Phase voltage 230V.Frequency 50Hz,power factor 0.8(lag).It can provide 60Hz and the other voltage's generator according to neccessary.They can be coupled with a prime mover directly or through V-belt making right or reverse continuous rotation at the rated speed.When the revolution slip of prime mover is 3% and load varies in the range of 0-100% cosθ 1.0-0.8 the give food constant voltage.After sudden change (increase or decrease) of load.The generators will soon return to their normal working state.Without any starting devices the generator can directly start an unloaded squirrel cage induction motor.
About stc 20 kva generator
| STC Series Single Phase A.C. Synchronous Generator / Alternator | |||||||||||||
| Model | Output (KW) | Current (A) | Voltage (V) | Power factor | Pole number | Speed r.p.m | N,W (kg) | G.W (kg) | Packing size | In a 20' container | Frequency(Hz) | ||
| Series connection | Parallel connection | Series connection | Parallel connection | 50/60 | |||||||||
| STC-2 | 2 | 8.7 | 17.4 | 230V | 115V | 1 | 4 | 1500/1800 | 43.5 | 46 | 52*29.5*46 | 425 | |
| STC-3 | 3 | 13 | 26 | 48.5 | 51 | 52*29.5*46 | 425 | ||||||
| STC-5 | 5 | 21.7 | 43.5 | 78 | 85 | 62*35*53 | 236 | ||||||
| STC-7.5/8 | 7.5/8 | 32.6 | 65.2 | 88 | 107 | 62*35*53 | 236 | ||||||
| STC-10 | 10 | 43.5 | 87 | 104.6 | 117 | 68*42*58 | 168 | ||||||
| STC-12 | 12 | 52.2 | 104.4 | 117 | 128 | 68*42*58 | 168 | ||||||
| STC-15 | 15 | 65.2 | 130.4 | 145 | 160 | 73*45*64 | 120 | ||||||
| STC-20 | 20 | 87 | 174 | 167 | 180 | 73*45*64 | 120 | ||||||
| STC-24 | 24 | 104 | 208 | 187 | 200 | ||||||||
