SHINVA Ampoule Steam/Super-heated Water Sterilizer (CE/ISO Certified)

Name: SHINVA Ampoule Steam/Super-heated Water Sterilizer (CE/ISO Certified)
Brand: SHINVA
SKU: 109186541
Availability: InStock

SHINVA Ampoule Steam/Super-heated Water Sterilizer (CE/ISO Certified) thumbnail-1

SHINVA Ampoule Steam/Super-heated Water Sterilizer (CE/ISO Certified) photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

SHINVA

Application:

Liquid

Contact Supplier Request Quote Chat Now

SHINVA Medical Instrument Co., Ltd. (Shandong)

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name SHINVA

Application Liquid

Type Other, Sterilization/Disinfection

Specifications

mainly used in the sterilization, leakage test and cleaning processing of ampoules, oral liquid (<20ml) infusion solution of

An ampoule sterilizer is mainly used in the sterilization, leakage test and cleaning processing of ampoules, oral liquid (<20ml) infusion solution of glass bottles, and other pharmaceutical preparations. After sterilization, unqualified products will be checked out with the help of vacuum and hue water.

Features:

The inner shell is composed of quality 304 stainless steel plates and is automatically welded by plasma which reduces heat affected zone and ensures good quality of the welded joint. The surface has gone through a minimum of 5 times' automatic mechanical polishing that makes it more tidy and corrosion-resistant. The exterior is composed of quality steel plates specially designed for pressure containers. In addition, the technology of welding robot automatic welding is applied, which makes the equipment more pressure-proof;
Electric lifted sealing door; cog locking; pneumatic sealing structure; the door board is made of a whole plank stuff; safety protection devices are installed on the door to protect the operator and the equipment from danger;
The pipeline is composed of quality 304 stainless steel seamless pipes; the equipment works steadily as all control and action elements are from internationally renowned brands;
The sterilizing trolley is of whole stainless steel frame structure which has a high space utilization;
Pure stainless steel external shell;
Energy loss and thermal radiation is efficiently reduced by quality silicate insulation cotton whose thickness is up to120mm;
There are three kinds of control modes during the process of sterilization for the operator to choose from: temperature and time control, FO value control, and temperature and time plus FO value control;
Powerful, reliable and nimble-using PLC mater controller

Product Classification:

SD/OD Series Ampoule Steam Sterilizer

Pressure steam is utilized as sterilizing medium and sterilization from 105°C to 127°C can be realized;
A touch screen is used as human-machine control interface on the upper machine which can dynamically display the work flow and make operation more convenient and direct viewing. Special configurations can be made and manual operation is doable.

ASMD Series Ampoule Super-heated Water Sterilizer

Inside this sterilizer, water of high temperature is showered to heat and sterilize liqiud bottles. Uniform sterilization can be realized from 70°C to 127°C. It owns the advantages of temperature uniformity, wide temperature control range and reliable regulation control.
The world-advanced computer configuration process control technology is applied in this machine. The control system is composed of the upper machine that sends orders and the lower machine that executes the orders. The whole machine is supported by advanced technologies and rich experience.
Lenovo commercial computers are used as human-machine control interface of the upper machine which can dynamically display the work flow and make operation more convenient and direct viewing. Special configurations can be made and manual operation is doable.
Cleaning is done twice, which not only is water-saving but also has a good effect.
