HLS90 90m3/h Compact Concrete Batching Plant With CE and ISO 9001 Mini Concrete Mixing Plant
- Qingdao
- T/T Money Gram
You May Like
-
HZS75 75m3/h CE Concrete Batching Plant
-
HZS40 40m3/h High Quality Toledo Load Cell Concrete Mixing Plant
-
HLS90 90m3/h Concrete Batching Plant With CE and ISO 9001
-
HLS120 120m3/h ce Iso Concrete Batching Plant With Low Price
-
HZS50 50m3/h CE Certified Toledo Load Cell Concrete Mixing Plant
-
HLS120 120m3/h Concrete Batching Plant
Product Details
| Condition | New | Power Type | Electric | |
| Place of Origin | Shandong, China | Brand Name | shitong | |
| Model Number | HLS90 | Power(W) | 100000 | |
| Dimension(L*W*H) | 53000x10000x12000 | Weight | 48T | |
| Certification | CE ISO9001 | Warranty | 12 month after built | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1 best quality & high production2 favorable price
3 customized
4 hot sell in concrete mixing plant market
The HLS series concrete mixing plant is an automatic concrete mixing assembly consisting of a batching, a mixing and an electrical control system. Equipped with a high-precision microcomputer control system and provision for separate manual control, the plant features formula memory, automatic drop compensation and sandstone moisture content compensation. This, together with a printing system supplied with the plant, enables automatic production of the preset tanks of concrete.
The plant features:
Modular construction allowing for easy integral installation and removal and low equipment cost.
A JS double horizontal shaft forced concrete mixer serving as the mixing machine and for aggregate lifting allowing for sound mixing quality and high efficiency.
A batching machine for aggregate batching allowing for accurate measurement and high production efficiency.
An electronic scale for weighing the powder, water and additives allowing for high batching precision.
Pump pressurized water supply allowing for faster flow and uniform distribution.
A belt conveyor for aggregate feeding allowing for long lifecycle and high work efficiency.
An electrical control system comprising imported key elements allowing for reliable performance and easy operation and furnished with printing and air conditioning.
Pleasant overall visual appearance, easy installation and disassembly, openable from the side of each layer of package allowing for access and replacement of fittings.
An aggregate lifting belt conveyor driven by electrical rollers allowing for steady operation, powerful dynamics and easy maintenance.
Followings are the parameters of the products:
| Model | HLS60 | HLS90 | HLS100 | HSL150 |
| Productivity | 60 | 90 | 100 | 150 |
| Mixer | JS1000 | JS1500 | JS2000 | JS3000 |
| Discharge height | 3.8 | 3.8 | 3.8 | 4 |
| Aggregate warehouse capacity | 3x12 m3 | 3x12 m3 | 4x20 m3 | 4x25 m3 |
| Aggregate transportation quantity | 160t | 210t | 600t | 800t |
| Production cycle | 60s | 66s | 72s | 72s |
| Main building weight | 30t | 40t | 50t | 75t |
| Aggregate measuring accuracy | ±1% | ±1% | ±2% | ±2% |
| Cement measuring accuracy | ±1% | ±1% | ±2% | ±1% |
| Fly ash measuring accuracy | ±1% | ±1% | ±2% | ±1% |
| Water measuring accuracy | ±1% | ±1% | ±2% | ±1% |
| Additive measuring accuracy | ±1% | ±1% | ±2% | ±1% |
| Cement screw conveyor | LSJ40 | LSJ90 | LSJ90 | LSJ150 |
| Fly ash screw conveyor | LSJ40 | LSJ40 | LSJ40 | LSJ40 |
| Plant power | 74Kw | 100Kw | 200Kw | 225Kw |
| Over dimension (mm)( L x W x H ) | 52000x10000x12000 | 53000x10000x12000 | 55000x18000x13000 | 56000x18000x33000 |
| Total weight | 36000Kg | 48000Kg | 78000Kg | 100000Kg |
Followings are the main photos of the main parts:
JS series Mixer
.Batch Device
Automatical Control System
Screw Conveyor
Cement Silo
We also have the following products:
1. Concrete batching plant
HZS series (HZS25 HZS40 HZS50 HZS75)

2. Mobile concrete mixing plant
3. Stabilizing soil mixing plant
4. Concrete mixier
5. Batching device
6. Screw conveyor
7. Cement silo
Please contact me for the detailed information and quotation. You are welcomed to visit our company to see the products. We want to achieve a long term win-win cooperation with you!
After-sale Service
1.May enjoy the life-long service after you buy our products.
2.Training the operator for free.
3. Under the condition that foundation, water source, power source, aggregate, hosting equipment, auxiliary staff is ready. Engineers are available if you need.
4.Certain quantity stochastic tool will be provided while delivering goods.
5.Within 48 hours service will be available according to different regions after received the telephone.
6. For exported products, Our company sends the constructor to help to operate and management equipment, time according to your needs. The related fee will be undertaken by buyers.
7. Promptly provides the fittings according to users’ demands, handles for the user consigns for shipment.
8. All products (easy worn parts not included) loss caused by non-human factors will be free of charge for half a year.
9. Provides the technology advisory service as necessary.
10. Please contact me via telephone 0086-18660191805 when you have any problems with the plant.
