Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > ZXWL WE2011 --- a Single-band Indoor AP With 2.4G for Coverage. Contact: Sherryt@versatek.cn

ZXWL WE2011 --- a Single-band Indoor AP With 2.4G for Coverage. Contact: Sherryt@versatek.cn

ZXWL WE2011 --- a Single-band Indoor AP With 2.4G for Coverage. Contact: Sherryt@versatek.cn thumbnail-1
ZXWL WE2011 --- a Single-band Indoor AP With 2.4G for Coverage. Contact: Sherryt@versatek.cn thumbnail-2
ZXWL WE2011 --- a Single-band Indoor AP With 2.4G for Coverage. Contact: Sherryt@versatek.cn thumbnail-3
ZXWL WE2011 --- a Single-band Indoor AP With 2.4G for Coverage. Contact: Sherryt@versatek.cn thumbnail-4
ZXWL WE2011 --- a Single-band Indoor AP With 2.4G for Coverage. Contact: Sherryt@versatek.cn photo-1
ZXWL WE2011 --- a Single-band Indoor AP With 2.4G for Coverage. Contact: Sherryt@versatek.cn photo-2
ZXWL WE2011 --- a Single-band Indoor AP With 2.4G for Coverage. Contact: Sherryt@versatek.cn photo-3
ZXWL WE2011 --- a Single-band Indoor AP With 2.4G for Coverage. Contact: Sherryt@versatek.cn photo-4
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
ZXWL WE2011
Model Number:
ZTE Versa/Versatek/VersaXpress
Contact Supplier Request Quote Chat Now
Versa Technology, Inc
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name ZXWL WE2011
Model Number ZTE Versa/Versatek/VersaXpress

1 General

The WE2011 is a single-band indoor AP with 2.4G for coverage. This high-performance 802.11n AP features lowering the installation time and cost of a room WLAN, and can be easily mounted in wall and match the decor of any room. Developed under the unified ZTE CSP software platform, it can easily switch and operate as coordinated or stand-alone AP, and provide a stable and manageable carrier-grade WLAN.


 Easy and Fast Installation

 Dual-software backup

 2.4G Single Band

 20 mW RF Output Power

 2X2 MIMO 2 Spatial Streams

 802.11b/g/n up to 300Mbps

 10/100Mbps Ethernet

 48V DC PoE Power Supply

 Coordinated / Stand-alone AP mode software switchable



1 Software Features



Radio Functions

• 100+ concurrent users

• Up to 16 SSIDs

• Coordinated / Stand-alone AP mode software switchable

• Load balance

• 802.1Q VLANs and VLAN Trunk

• Static , DHCP (OPTION43/60) IP assignment

• Dynamic user Bandwidth Limitation

• Dynamic frequency selection (DFS) optimizes the use of RF spectrum

• A-MPDU

• Auto RF power adjustment, configurable step of 1 dBm

• IETF CAPWAP Taxonomy and Architecture compatibility

Security

• Layer 2 wireless client isolation

• 802.1x authentication using EAP-SIM/AKA, PEAP, TLS, TTLS

• 802.11i Wi-Fi WPA2 or WPA

• WAPI-Wireless LAN Authentication and Privacy Infrastructure

QoS

• IEEE 802.1p prioritization

• IEEE 802.11e EDCF

• Wi-Fi Multi Media (WMM)

Management

• IPV4 / IPV6 dual stacks

• Embedded HTTP / HTTPs and telnet

• SNMP v2c, SNMP v3, MIB-II with Traps

• NTP Network Time Protocol

• Configuration and software upgrades from Access Controller



1 Technical Indices

1.1 Radio Indices

Standards

IEEE 802.11b/g/n

802.11b:BPSK, QPSK, CCK

802.11g/n: BPSK, QPSK, 16-QAM, 64-QAM

PHY Data Rate

802.11b: 1,2,5.5, 11Mbps (DSSS)

802.11g: 6,9,12,18,24,36,48,54Mbps (OFDM)

802.11n: MCS0 to MCS15 up to 300Mbps

Radio Chains

2X2 MIMO 2 Spatial Streams

MRC for improved receiver performance

Cyclic delay diversity for improved downlink RF performance

STBC for increased range and reception

Frequency Band

2.4-2.484GHz

Dual-radio, single-band 802.11n indoor wall-in

Channelization

HT 20MHz / 40MHz

RF Transmit Power

2.4G Hz : Max 20 mW

Encryption

64/128-bit WEP

WPA-PSK, WPA2-PSK

WPA-Enterprise, WPA2-Enterprise

TKIP and AES/CCMP

1.2 Physical Indices

RF Interface

Internal antenna

Network Interface

2 * RJ-45 for Fast Ethernet, one for WAN and the other for LAN

Auto-MDIX and POE

Other Interface

2 * RJ-11 phone interface, one for input and one for output

Reset button: push to reset, push and hold on for 5s to restore the default configuration;

Environmental Condition

Indoor IP30

Work Temperature -10°C to 45°C

Humidity 5 to 95% non-condensing

Power Rating

3.0 W(Typical )

Power Supply

48V DC PoE 802.3af/at

Dimensions

41.5 (D) x 54.5 (W) x 65.5 (H) mm

Weight

0.105 kg
