VX-H368N VDSL2 Home Gateway; Contact: Sherry@versatek.cn

VDSL2 Broadband Router is powered by Versa’s proven Network Processor with integrated VDSL2,

providing up to 100Mbps speeds over VDSL2 lines and 300Mbps over 802.11n.The VDSL2 Router offers

high performance with low CPU utilization using a unique Hardware and Software Packet Acceleration

technology offered by Versa Software stacks. This is an ideal solution for users looking for high

performance low cost router for residential use.

Versa, in partnership with ODM, offers a ready to deploy VDSL2 Router that enables Carriers a faster

time-to-deploy.

4-ports|802.11b/g/n|VoIP|USB Host

Hardware Specifications

²   One VDSL2/ADSL2+ Line with Auto fall back

²   Four 10/100 Base T Ethernet LAN

²   One USB2.0 Port

²   One FXS POTS interface (Optional)

²   Wireless Antennas: 2x2

²   802.11b/g/n , 2.4GHz

²   Wireless ON/OFF Button

²   WPS Button

²   Reset Button

²   Auto switching between ADSL2+/VDSL2

²   Status LED Indicators : PWR, xDSL, Internet,

²   Wi-Fi, WPS, Eth1, Eth2, Eth3, Eth4, USB,

²   Voice

²   Power Supply : 18Watt (12V/1.5A)

²   Two Layer PCB

²   ECoC v5 compliant

²  Dimension : 187 mm x 130 mm x 35mm

Physical Specifications

²   Environmental

Operating Temperature:

Input 100-240VAC±10%; Output 12VDC

Temperature: 0 to 40°C (32 to 96°F)

Humidity: 20% to 90% (non-condensing)

²   Certifications

EMC & Safety

Versa Certifications

²   A/VDSL Features

ADSL2+ WAN - ITU-T G992.1

ADSL2+ WAN - ITU-T G992.3

ADSL2+ WAN - ITU-T G992.5

ADSL2+ WAN - ANSI T1.413

VDSL2 WAN - ITU-T G993.2

VDSL Vectoring - ITU-T G993.5

xDSL WAN Negotiation

Seamless switching between ADSL2+ and VDSL2

Industry proven Interoperability

ATM protocol support on PVC

Multiprotocol Encapsulation over AAL5

PPPoATM

ATM QoS

²   Routing and Bridging

802.1d Learning Bridge and Bridge Filtering

Static IPv4/IPv6 Routing

Destination IP address based routing

Point-To-Point Protocol

PPP Internet Protocol Control Protocol (IPCP)

NAT/NAPT

PAP/CHAP

PPPoE Relay

PPPoE

Event Logging

TCP/IP/UDP

DS-Lite

VLAN

ALG

DHCP

HTTP

IGMPv3/MLDv2

²   Quality of Service

VLAN QoS: 802.1p, 802.1q

ATM tra_c classes

Di_serv and Marking

Application based QoS (Layer 7)

Hardware assisted QoS

Prioritization of Voice over Data

Multicast support

Best user experience

²   Voice

G.711/G.729AB Codec support T.38

3-way conferencing

Country Specific settings

Carrier Grade Voice

Widely Deployed Voice solution

²   Management

Firmware upgrade

Diagnostics

Remote Device Management

Web UI for configuration Management

²   Transfer Rates

100Mbps over VDSL2

300Mbps over WLAN
